    CHIEFTEC PPG-850-S

  • Brand: CHIEFTEC
  • Product Code: PPG-850-S
  • EAN: 753263078797
  • Availability: 100
80.11€
Ex Tax: 66.21€
  • Product overview
  • Specification
  • Reviews (0)

Tags: Desktop Computer PSU

Specifications
Specifikācija
Cabling type Non-Modular
CPU power cable length 650
EPS power connector (4+4 pin) Yes
Motherboard power cable length 600
PCI Express power cable length 600
PCI Express power connectors (12+4 pin) 1
PCI Express power connectors (12+4 pin) cable length 600
Peripheral (Molex) power cable length 400
Power supply unit (PSU) form factor ATX
Product colour Black
Purpose PC
SATA power cable length 400
Summary Chieftec Vega PPG-850-S Watt. Total power: 850 W, AC input voltage: 100 - 240 V, Power protection features: Over current, Over power, Over voltage, Overheating, Short circuit, Surge & inrush protection.... Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 60 cm, SATA power cable length: 400 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Certification: 80PLUS Gold
Unit Calculated Volume 0.007626
Unit Calculated Weight 2.54
Units per Shipping Box 5
Processor parameters
CPU power connector (4+4 pin) Yes
Storage parameters
Number of SATA power connectors 6
Specifications
80 PLUS certification 80 PLUS Gold
AC input voltage 100 - 240
ATX power connector (20+4 pin) Yes
ATX Power connector (24-pin) Yes
ATX version 3.1
Bearing technology FDB
Certification 80PLUS Gold
Cooling type Active
EPS power connector (8-pin) Yes
Fan diameter 135
Illumination No
Model name PPG-850-S
Motherboard power connector 20+4 pin ATX
Number of fans 1
Package weight 2540
PCI Express power connectors (6+2 pin) 4
Peripheral (Molex) power connectors (4-pin) 3
Power protection features Over current/Over power/Over voltage/Overheating/Short circuit/Surge & inrush protection (SIP)/Surge and inrush/Under voltage
Total power 850
Weight 2070
