Mainboard, ASROCK, Memory DDR5, Memory slots 4, 1xPCI-Express 4.0 16x, 1xPCI-Express 5.0 16x, 1xM.2, 1xHDMI, 1xDisplayPort, 1xAudio-In, 1xAudio-Out, 1xMicrophone, 2xUSB 2.0, 6xUSB 3.2, 1xUSB-C, 1xRJ45, B860PRORSWIFI

Populārs

Atsauksmes:

(0)

Nosaukums:

ASROCK B860 PRO RS WIFI

Ražotājs: ASROCK
Modelis: B860 PRO RS WIFI
EAN: 4711581490239
Pieejamība: 4

156,33€

Bez PVN: 129,20€

Daudzums:

Produktu apskats
Specifikācija
Atsauksmes (0)

Manufacturer page

Atslēgvārdi: Mainboards for Intel CPUs

Specifikācijas

Specifikācija

Antenna included Yes

Audio chip Realtek ALC897

BIOS memory size 256

CPU fan connector Yes

ECC сompatibility Non-ECC

Front panel audio connector Yes

Motherboard chipset family Intel

Number of chassis fan connectors 4

Number of CPU fan connectors 2

Number of M.2 (M) slots 1

Number of SATA III connectors 4

PCI Express x16 (Gen 4.x) slots 1

PCI Express x16 (Gen 5.x) slots 1

RGB LED pin header Yes

Summary Asrock B860 Pro RS WiFi. Processor manufacturer: Intel, Processor socket: LGA 1851 (Socket V1), Compatible processor series: Intel Core Ultra (Series 2). Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Ethernet interface type: 2.5 Gigabit Ethernet, LAN controller: Dragon RTL8125BG, Top Wi-Fi standard: Wi-Fi 6E (802.11ax). Component for: PC, Motherboard form factor: ATX, Motherboard chipset family: Intel

Supported memory clock speed (max) 8666

Top Wi-Fi standard Wi-Fi 6E (802.11ax)

TPM connector Yes

Unit Calculated Volume 0.008784

Unit Calculated Weight 1.97

Units per Shipping Box 5

USB 3.2 Gen 1 (3.1 Gen 1) connectors 3

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 6

USB 3.2 Gen 2x2 Type-C ports quantity 1

Procesors

Compatible processor series Intel Core Ultra (Series 2)

Processor manufacturer Intel

Atmiņa

Atmiņas tips DDR5

Maximum internal memory 256

Memory channels Dual-channel

Memory slots type DIMM

Supported memory types DDR5-SDRAM

Unbuffered memory Yes

Atmiņas ierīce

RAID levels 0/1/10/5

RAID support Yes

Supported storage drive interfaces M.2,SATA III

Supported storage drive types HDD & SSD

Porti

DisplayPort version 1.4

DisplayPorts quantity 1

HDMI portu daudzums 1

Microphone in Yes

USB 2.0 connectors 2

USB 2.0 ports quantity 2

Pieslēgumi

Bluetooth Yes

Bluetooth versija 5.3

Ethernet interface type 2.5 Gigabit Ethernet

Ethernet LAN Yes

Ethernet LAN (RJ-45) porti 1

LAN controller Dragon RTL8125BG

Wi-Fi Yes

Wi-Fi standards 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)/Wi-Fi 6E (802.11ax)

Specifikācijas

ATX Power connector (24-pin) Yes

Audio output channels 7.1

BIOS Type UEFI AMI

Component for PC

Dziļums 244

EPS power connector (8-pin) Yes

Form factor ATX

HDCP Yes

Komplektā kabeļi SATA

Line-in Yes

Mikroshēmu komplekts B860

Model B860 Pro RS WiFi

Motherboard chipset Intel B860

Motherboard form factor ATX

Number of memory slots 4

Peripheral (Molex) power connectors (4-pin) 1

Platums 305

Windows operating systems supported Windows 11 x64
