Mainboard, GIGABYTE, AMD B850, SAM5, ATX, Memory DDR5, Memory slots 4, 2xPCI-Express 3.0 1x, 1xPCI-Express 4.0 4x , 1xPCI-Express 5.0 16x, 3xM.2, 1xHDMI, 1xDisplayPort, 4xUSB 2.0, 2xUSB 3.2, 1xUSB-C, 1xRJ45, 3xAudio port, B850EAGLEICE
Populārs
Mainboard, GIGABYTE, AMD B850, SAM5, ATX, Memory DDR5, Memory slots 4, 2xPCI-Express 3.0 1x, 1xPCI-Express 4.0 4x , 1xPCI-Express 5.0 16x, 3xM.2, 1xHDMI, 1xDisplayPort, 4xUSB 2.0, 2xUSB 3.2, 1xUSB-C, 1xRJ45, 3xAudio port, B850EAGLEICE
Mainboard, GIGABYTE, AMD B850, SAM5, ATX, Memory DDR5, Memory slots 4, 2xPCI-Express 3.0 1x, 1xPCI-Express 4.0 4x , 1xPCI-Express 5.0 16x, 3xM.2, 1xHDMI, 1xDisplayPort, 4xUSB 2.0, 2xUSB 3.2, 1xUSB-C, 1xRJ45, 3xAudio port, B850EAGLEICE
Mainboard, GIGABYTE, AMD B850, SAM5, ATX, Memory DDR5, Memory slots 4, 2xPCI-Express 3.0 1x, 1xPCI-Express 4.0 4x , 1xPCI-Express 5.0 16x, 3xM.2, 1xHDMI, 1xDisplayPort, 4xUSB 2.0, 2xUSB 3.2, 1xUSB-C, 1xRJ45, 3xAudio port, B850EAGLEICE
Mainboard, GIGABYTE, AMD B850, SAM5, ATX, Memory DDR5, Memory slots 4, 2xPCI-Express 3.0 1x, 1xPCI-Express 4.0 4x , 1xPCI-Express 5.0 16x, 3xM.2, 1xHDMI, 1xDisplayPort, 4xUSB 2.0, 2xUSB 3.2, 1xUSB-C, 1xRJ45, 3xAudio port, B850EAGLEICE
Atsauksmes:
(0)
    Nosaukums:

    Gigabyte B850 EAGLE ICE

  • Ražotājs: Gigabyte
  • Modelis: B850 EAGLE ICE
  • EAN: 4719331871680
  • Pieejamība: 11
176,66€
Bez PVN: 146,00€
  • Produktu apskats
  • Specifikācija
  • Atsauksmes (0)

Atslēgvārdi: Mainboards for AMD CPUs

Specifikācijas
Specifikācija
12V power connector Да
1st M.2 highest PCI Express generation 5.0
1st M.2 largest key size 22110
2nd M.2 highest PCI Express generation 4.0
2nd M.2 largest key size 22110
3rd M.2 highest PCI Express generation 4.0
3rd M.2 largest key size 22110
ACPI version 5.0
Audio chip Realtek ALC897
BIOS memory size 256
Clear CMOS jumper Да
CPU fan connector Да
Desktop Management Interface (DMI) version 2.7
ECC ?ompatibility Non-ECC
Front panel audio connector Да
Front panel connector Да
Lithium weight per battery 0.07
Maximum internal memory per slot 64
Motherboard chipset family AMD
Number of chassis fan connectors 4
Number of CPU fan connectors 2
Number of EPS power connectors (8-pin) 1
Number of HDDs supported 4
Number of M.2 (M) slots 3
Number of RGB LED pin headers 4
Number of SATA III connectors 4
Number of water pump connectors 2
Parallel processing technology support Не поддерживается
PC health monitoring Water cooling/Вентилятор/Напряжение/Температура
PCI Express x16 (Gen 3.x) slots 2
PCI Express x16 (Gen 4.x) slots 1
PCI Express x16 (Gen 5.x) slots 1
Product colour Белый
Products per shipping (inner) case 1
Screws included Да
Summary GIGABYTE B850 EAGLE ICE. Производитель процессора: AMD, Сокет процессора: Socket AM5, Совместимые серии процессоров: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series. Поддерживаемые типы памяти: DDR5-SDRAM, Максимальная внутренняя память: 256 GB, Тип слотов памяти: DIMM. Поддерживаемые интерфейсы носителя: M.2, PCI Express 4.0, PCI Express 5.0, SATA III, Поддерживаемые типы накопителей: HDD & SSD, Уровни RAID: 0, 1, 10. Максимальное разрешение: 4096 x 2160 пикселей. Тип Ethernet интерфейса: 2.5 Gigabit Ethernet, Контроллер LAN: Realtek RTL8125
Supported memory clock speed (max) 8200
System Management BIOS (SMBIOS) version 2.7
TPM connector Да
USB 3.2 Gen 1 (3.1 Gen 1) connectors 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 2
Warranty period 3
Вес в упаковке 1.87
Количество в транспортной упаковке 8
Модель B850 EAGLE ICE
Объем 0.01007
Procesors
Compatible processor series AMD Ryzen 7000 Series/AMD Ryzen 8000 Series/AMD Ryzen 9000 Series
Procesoru ligzda AM5
Processor manufacturer AMD
Atmiņa
Atmiņas tips DDR5
Maximum internal memory 256
Memory channels Dual-channel
Memory slots type DIMM
Supported memory clock speeds 4400/4800/5200/5600/5800/6000/6200/6400/6600/6800/7000/7200/7400/7600/7800/7900/7950/8000/8200
Supported memory types DDR5-SDRAM
Unbuffered memory Да
Atmiņas ierīce
Number of storage drives supported 7
RAID levels 0/1/10
RAID support Да
Supported storage drive interfaces M.2,PCI Express 4.0,PCI Express 5.0,SATA III
Supported storage drive types HDD & SSD
Porti
DisplayPort version 1.4
DisplayPorts quantity 1
HDMI portu daudzums 1
HDMI version 2.1
Headphone outputs 1
Microphone in Да
USB 2.0 connectors 2
USB 2.0 ports quantity 4
Pieslēgumi
Ethernet interface type 2.5 Gigabit Ethernet
Ethernet LAN Да
Ethernet LAN (RJ-45) porti 1
LAN controller Realtek RTL8125
Wi-Fi Нет
Akumulators
Akumulatora elementu skaits 1
Baterijas tehnoloģija Lithium-Manganese Dioxide (LiMnO2)
Batteries included Да
Battery type CR2032
Battery weight 3
Specifikācijas
ATX Power connector (24-pin) Да
Audio output channels 7.1
Augstums 35
BIOS Type UEFI AMI
Bundled software Norton® Internet Security (OEM version)LAN bandwidth management software
Component for ПК
Cooling type Пассивный
Country of origin Китай
DirectX version 12.0
Dziļums 244
EPS power connector (8-pin) Да
Form factor ATX
HDCP Да
Line-in Да
Maximum resolution 4096 x 2160
Mikroshēmu komplekts B850
Motherboard chipset AMD B850
Motherboard form factor ATX
Number of memory slots 4
Package depth 270
Package height 80
Package weight 1882
Package width 335
Peripheral (Molex) power connectors (4-pin) 1
Platums 305
Power source type ATX
PS/2 ports quantity 1
Supported processor sockets Socket AM5
Weight 1650
Windows operating systems supported Windows 11 x64
