Mainboard, GIGABYTE, AMD B850, SAM5, Micro-ATX, Memory DDR5, Memory slots 2, B850MFORCE

Populārs

Atsauksmes:

(0)

Nosaukums:

Gigabyte B850M FORCE

Ražotājs: Gigabyte
Modelis: B850M FORCE
EAN: 4719331874322
Pieejamība: 22

131,21€

Bez PVN: 108,44€

Daudzums:

Produktu apskats
Specifikācija
Atsauksmes (0)

Manufacturer page

Atslēgvārdi: Mainboards for AMD CPUs

Specifikācijas

Specifikācija

12V power connector Yes

1st M.2 highest PCI Express generation 5.0

1st M.2 largest key size 2280

2nd M.2 highest PCI Express generation 4.0

2nd M.2 largest key size 2280

3rd M.2 highest PCI Express generation 4.0

3rd M.2 largest key size 2280

ACPI version 5.0

Audio chip Realtek ALC897

BIOS memory size 256

Clear CMOS jumper Yes

CPU fan connector Yes

Desktop Management Interface (DMI) version 2.7

ECC сompatibility Non-ECC

Front panel audio connector Yes

Front panel connector Yes

Lithium weight per battery 0.07

Maximum internal memory per slot 64

Motherboard chipset family AMD

Number of chassis fan connectors 2

Number of CPU fan connectors 2

Number of EPS power connectors (8-pin) 1

Number of HDDs supported 4

Number of M.2 (M) slots 3

Number of RGB LED pin headers 4

Number of SATA III connectors 4

Number of water pump connectors 2

Parallel processing technology support Not supported

PC health monitoring Fan/Temperature/Voltage/Water cooling

PCI Express x16 (Gen 4.x) slots 1

PCI Express x16 (Gen 5.x) slots 1

Product colour Dark brown

Products per shipping (inner) case 1

RGB LED pin header Yes

Screws included Yes

Summary GIGABYTE B850M FORCE Motherboard - AMD Ryzen 9000 Series CPUs, 8+2+2 Phases Digital VRM, up to 9600MHz DDR5 (OC), 1xPCIe 5.0 + 2xPCIe 4.0 M.2, 2.5 GbE LAN, USB 3.2 Gen 2. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series. Supported memory types: DDR5-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, PCI Express 4.0, PCI Express 5.0, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Maximum resolution: 4096 x 2160 pixels. Ethernet interface type: 2.5 Gigabit Ethernet, LAN controller: Realtek RTL8125

Supported memory clock speed (max) 9600

System Management BIOS (SMBIOS) version 2.7

TPM connector Yes

Unit Calculated Volume 0.007068

Unit Calculated Weight 1.36

Units per Shipping Box 8

USB 3.2 Gen 1 (3.1 Gen 1) connectors 2

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity 1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 1

Warranty period 3

Procesors

Compatible processor series AMD Ryzen 7000 Series/AMD Ryzen 8000 Series/AMD Ryzen 9000 Series

Procesoru ligzda AM5

Processor manufacturer AMD

Atmiņa

Atmiņas tips DDR5

Maximum internal memory 128

Memory channels Dual-channel

Memory slots type DIMM

Supported memory clock speeds 4400/4800/5200/5600/6000/6200/6400/6600/6666/6800/7000/7200/7600/7800/8000/8200/8400/8600/8800/9200/9600

Supported memory types DDR5-SDRAM

Unbuffered memory Yes

Atmiņas ierīce

Number of storage drives supported 7

RAID levels 0/1/10/5

RAID support Yes

Supported storage drive interfaces M.2,PCI Express 4.0,PCI Express 5.0,SATA III

Supported storage drive types HDD & SSD

Porti

DisplayPort version 1.4

DisplayPorts quantity 1

HDMI portu daudzums 1

HDMI version 2.1

Headphone outputs 1

Microphone in Yes

USB 2.0 connectors 2

USB 2.0 ports quantity 2

Pieslēgumi

Ethernet interface type 2.5 Gigabit Ethernet

Ethernet LAN Yes

Ethernet LAN (RJ-45) porti 1

LAN controller Realtek RTL8125

Wi-Fi No

Akumulators

Akumulatora elementu skaits 1

Baterijas tehnoloģija Lithium-Manganese Dioxide (LiMnO2)

Batteries included Yes

Battery type CR2032

Battery weight 3

Specifikācijas

ATX Power connector (24-pin) Yes

Audio output channels 7.1

Augstums 35

BIOS Type UEFI AMI

Bundled software Norton® Internet Security (OEM version)

Component for PC

Cooling type Passive

Country of origin China

DirectX version 12.0

Dziļums 244

EPS power connector (8-pin) Yes

Form factor mATX

HDCP Yes

Line-in Yes

Maximum resolution 4096 x 2160

Mikroshēmu komplekts B850

Model B850M FORCE

Motherboard chipset AMD B850

Motherboard form factor micro ATX

Number of memory slots 2

Package depth 268

Package height 68

Package weight 1400

Package width 270

Platums 244

Power source type ATX

PS/2 ports quantity 1

Supported processor sockets Socket AM5

Weight 1180

Windows operating systems supported Windows 10 x64/Windows 11 x64
