Mainboard, GIGABYTE, Intel Z790, LGA1700, ATX, Memory DDR5, Memory slots 4, 3xPCI-Express 3.0 1x, 1xPCI-Express 4.0 4x , 1xPCI-Express 5.0 16x, 3xM.2, 1xHDMI, 1xDisplayPort, 6xUSB 2.0, 6xUSB 3.2, 1xUSB-C, 1xPS/2, 1xOptical S/PDIF, 1xRJ45, 3xAudio port, Z7
Populārs
Mainboard, GIGABYTE, Intel Z790, LGA1700, ATX, Memory DDR5, Memory slots 4, 3xPCI-Express 3.0 1x, 1xPCI-Express 4.0 4x , 1xPCI-Express 5.0 16x, 3xM.2, 1xHDMI, 1xDisplayPort, 6xUSB 2.0, 6xUSB 3.2, 1xUSB-C, 1xPS/2, 1xOptical S/PDIF, 1xRJ45, 3xAudio port, Z7
Mainboard, GIGABYTE, Intel Z790, LGA1700, ATX, Memory DDR5, Memory slots 4, 3xPCI-Express 3.0 1x, 1xPCI-Express 4.0 4x , 1xPCI-Express 5.0 16x, 3xM.2, 1xHDMI, 1xDisplayPort, 6xUSB 2.0, 6xUSB 3.2, 1xUSB-C, 1xPS/2, 1xOptical S/PDIF, 1xRJ45, 3xAudio port, Z7
Mainboard, GIGABYTE, Intel Z790, LGA1700, ATX, Memory DDR5, Memory slots 4, 3xPCI-Express 3.0 1x, 1xPCI-Express 4.0 4x , 1xPCI-Express 5.0 16x, 3xM.2, 1xHDMI, 1xDisplayPort, 6xUSB 2.0, 6xUSB 3.2, 1xUSB-C, 1xPS/2, 1xOptical S/PDIF, 1xRJ45, 3xAudio port, Z7
Mainboard, GIGABYTE, Intel Z790, LGA1700, ATX, Memory DDR5, Memory slots 4, 3xPCI-Express 3.0 1x, 1xPCI-Express 4.0 4x , 1xPCI-Express 5.0 16x, 3xM.2, 1xHDMI, 1xDisplayPort, 6xUSB 2.0, 6xUSB 3.2, 1xUSB-C, 1xPS/2, 1xOptical S/PDIF, 1xRJ45, 3xAudio port, Z7
Mainboard, GIGABYTE, Intel Z790, LGA1700, ATX, Memory DDR5, Memory slots 4, 3xPCI-Express 3.0 1x, 1xPCI-Express 4.0 4x , 1xPCI-Express 5.0 16x, 3xM.2, 1xHDMI, 1xDisplayPort, 6xUSB 2.0, 6xUSB 3.2, 1xUSB-C, 1xPS/2, 1xOptical S/PDIF, 1xRJ45, 3xAudio port, Z7
Atsauksmes:
(0)
    Nosaukums:

    Gigabyte Z790 EAGLE 1.0

  • Ražotājs: Gigabyte
  • Modelis: Z790 EAGLE 1.0
  • EAN: 4719331860981
  • Pieejamība: 13
184,02€
Bez PVN: 152,08€
  • Produktu apskats
  • Specifikācija
  • Atsauksmes (0)

Atslēgvārdi: Mainboards for Intel CPUs

Specifikācijas
Specifikācija
1st M.2 highest PCI Express generation 4.0
1st M.2 largest key size 22110
2nd M.2 highest PCI Express generation 4.0
2nd M.2 largest key size 2280
3rd M.2 highest PCI Express generation 4.0
3rd M.2 largest key size 2280
ACPI version 5.0
Audio chip Realtek ALC897
BIOS memory size 256
Clear CMOS jumper Yes
CPU fan connector Yes
Desktop Management Interface (DMI) version 2.7
ECC ?ompatibility ECC & Non-ECC
Front panel audio connector Yes
Front panel connector Yes
Lithium weight per battery 0.07
Maximum internal memory per slot 64
Motherboard chipset family Intel
Number of chassis fan connectors 4
Number of CPU fan connectors 2
Number of EPS power connectors (8-pin) 2
Number of HDDs supported 4
Number of M.2 (M) slots 3
Number of RGB LED pin headers 2
Number of SATA III connectors 4
Number of water pump connectors 2
Parallel processing technology support Not supported
PC health monitoring Fan/Temperature/Voltage/Water cooling
PCI Express x1 (Gen 3.x) slots 2
PCI Express x16 (Gen 3.x) slots 1
PCI Express x16 (Gen 4.x) slots 1
PCI Express x16 (Gen 5.x) slots 1
Product colour Black
Product Net Weight 0.7
Products per shipping (inner) case 1
RGB LED pin header Yes
S/PDIF out connector Yes
Screws included Yes
Summary GIGABYTE Z790 EAGLE Motherboard - Supports 14th Gen. Intel Core CPUs, 12+1+1 phases VRM, up to 7600MHz DDR5 (OC), 3xPCIe 4.0 M.2, 2,5GbE LAN, USB 3.2 Gen 2. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processor series: Intel® Celeron®, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel.... Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Maximum resolution: 4096 x 2304 pixels. Ethernet interface type: 2.5 Gigabit Ethernet, LAN controller: Realtek RTL8125
Supported memory clock speed (max) 7600
System Management BIOS (SMBIOS) version 2.7
Thunderbolt headers 2
TPM connector Yes
Unit Calculated Volume 0.01038
Unit Calculated Weight 1.82
Units per Shipping Box 8
USB 3.2 Gen 1 (3.1 Gen 1) connectors 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 1
Warranty period 3
Procesors
Compatible processor series Intel Celeron/Intel Core/Intel Core i3 12th Gen/Intel Core i3 13th Gen/Intel Core i3 14th Gen/Intel Core i5 12th Gen/Intel Core i5 13th Gen/Intel Core i5 14th Gen/Intel Core i7 12th Gen/Intel Core i7 13th Gen/Intel Core i7 14th Gen/Intel Core i9 12th Gen
Processor manufacturer Intel
Atmiņa
Atmiņas tips DDR5
Maximum internal memory 256
Memory channels Dual-channel
Memory slots type DIMM
Supported memory clock speeds 4400/4800/5200/5400/5600/5800/6000/6200/6400/6600/6800/7000/7200/7400/7600
Supported memory types DDR5-SDRAM
Unbuffered memory Yes
Atmiņas ierīce
Number of storage drives supported 7
RAID levels 0/1/10/5
RAID support Yes
Supported storage drive interfaces M.2,SATA III
Supported storage drive types HDD & SSD
Porti
DisplayPort version 1.2
DisplayPorts quantity 1
HDMI portu daudzums 1
HDMI version 2.1
Headphone outputs 1
USB 2.0 connectors 2
USB 2.0 ports quantity 2
Pieslēgumi
Ethernet interface type 2.5 Gigabit Ethernet
Ethernet LAN Yes
Ethernet LAN (RJ-45) porti 1
LAN controller Realtek RTL8125
Wi-Fi No
Akumulators
Akumulatora elementu skaits 1
Baterijas tehnoloģija Lithium-Manganese Dioxide (LiMnO2)
Batteries included Yes
Battery type CR2032
Battery weight 3
Specifikācijas
ATX Power connector (24-pin) Yes
Audio output channels 7.1
Augstums 35
BIOS Type UEFI AMI
Bundled software Norton® Internet Security (OEM version)LAN bandwidth management software
Component for PC
Country of origin China
DirectX version 12.0
Dziļums 244
EPS power connector (8-pin) Yes
Form factor ATX
HDCP Yes
Line-in Yes
Maximum resolution 4096 x 2304
Mikroshēmu komplekts Z790
Model Z790 EAGLE (rev. 1.0)
Motherboard chipset Intel Z790
Motherboard form factor ATX
Number of memory slots 4
Package depth 270
Package height 80
Package weight 1792.5
Package width 335
Platums 305
Power source type ATX
PS/2 ports quantity 1
Supported processor sockets LGA 1700
Windows operating systems supported Windows 10 x64/Windows 11 x64
