Power Supply, GIGABYTE, UD1300GM PG5, 1300 Watts, Efficiency 80 PLUS GOLD, PFC Active, MTBF 100000 hours, GP-UD1300GMPG5
Populārs
Power Supply, GIGABYTE, UD1300GM PG5, 1300 Watts, Efficiency 80 PLUS GOLD, PFC Active, MTBF 100000 hours, GP-UD1300GMPG5
Power Supply, GIGABYTE, UD1300GM PG5, 1300 Watts, Efficiency 80 PLUS GOLD, PFC Active, MTBF 100000 hours, GP-UD1300GMPG5
Power Supply, GIGABYTE, UD1300GM PG5, 1300 Watts, Efficiency 80 PLUS GOLD, PFC Active, MTBF 100000 hours, GP-UD1300GMPG5
Power Supply, GIGABYTE, UD1300GM PG5, 1300 Watts, Efficiency 80 PLUS GOLD, PFC Active, MTBF 100000 hours, GP-UD1300GMPG5
Power Supply, GIGABYTE, UD1300GM PG5, 1300 Watts, Efficiency 80 PLUS GOLD, PFC Active, MTBF 100000 hours, GP-UD1300GMPG5
Power Supply, GIGABYTE, UD1300GM PG5, 1300 Watts, Efficiency 80 PLUS GOLD, PFC Active, MTBF 100000 hours, GP-UD1300GMPG5
Power Supply, GIGABYTE, UD1300GM PG5, 1300 Watts, Efficiency 80 PLUS GOLD, PFC Active, MTBF 100000 hours, GP-UD1300GMPG5
Atsauksmes:
(0)
    Nosaukums:

    Gigabyte GP-UD1300GMPG5

  • Ražotājs: Gigabyte
  • Modelis: GP-UD1300GMPG5
  • EAN: 4719331553388
  • Pieejamība: 16
190,10€
Bez PVN: 157,11€
  • Produktu apskats
  • Specifikācija
  • Atsauksmes (0)

Atslēgvārdi: Desktop Computer PSU

Specifikācijas
Specification
Noise level 40
Specifikācija
Cable tie(s) included Yes
Cabling type Fully-Modular
Compliance certificates CCC/CE/Federal Communications Commission (FCC)/RoHS
Hold time 16
Maximum input current (@220V) 12
Motherboard power cable length 610
Number of PATA power connectors 3
PCI Express power cable length 700
PCI Express power connectors (16-pin) 1
Peripheral (Molex) power cable length 200/600
Power supply unit (PSU) form factor ATX
Product colour Black
Purpose PC
SATA power cable length 150/600
Summary GIGABYTE UD1300GM PG5. Total power: 1300 W, AC input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 61 cm, SATA power cable length: 150,600 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Cables included: CPU, PATA, Peripheral (Molex), SATA
Unit Calculated Volume 0.01101
Unit Calculated Weight 4.17
Units per Shipping Box 1
Warranty period 5
Procesors
CPU power connector (4+4 pin) Yes
Atmiņas ierīce
Number of SATA power connectors 8
Specifikācijas
80 PLUS certification 80 PLUS Gold
AC input frequency 50 - 60
AC input voltage 100 - 240
ATX power connector (20+4 pin) Yes
Augstums 86
Combined power (+12V) 1300
Combined power (+3.3V) 125
Combined power (+5V) 125
Combined power (+5Vsb) 17.5
Combined power (-12V) 3.6
Cooling type Active
Dziļums 160
Efficiency 90
Fan diameter 120
Fan location Top
Illumination No
Input current 12 - 6
Komplektā kabeļi CPU,PATA,Peripheral (Molex),SATA
Max output current (+12V) 108.3
Max output current (+3.3V) 25
Max output current (+5V) 25
Max output current (+5Vsb) 3.5
Max output current (-12V) 0.3
Maximum input current (@110V) 6
Mean time between failures (MTBF) 100000
Modeļa nosaukums UD1300GM PG5
Motherboard power connector 20+4 pin ATX
Number of fans 1
Package type Box
PCI Express connector Yes
PCI Express power connectors (6+2 pin) 4
Peripheral (Molex) power connectors (4-pin) 2
Platums 150
Power Factor Correction (PFC) type Active
Power protection features Over current/Over power/Over voltage/Overheating/Short circuit/Under voltage
Total power 1300
