Switch, TP-LINK, Omada, TL-SG3452X, Type L2+, Rack, 48x10Base-T / 100Base-TX / 1000Base-T, 4xSFP+, 1xConsole, 1, TL-SG3452X

Populārs

Pēdējais

Switch, TP-LINK, Omada, TL-SG3452X, Type L2+, Rack, 48x10Base-T / 100Base-TX / 1000Base-T, 4xSFP+, 1xConsole, 1, TL-SG3452X

Atsauksmes:

(0)

Nosaukums:

TP-LINK TL-SG3452X

Ražotājs: TP-LINK
Modelis: TL-SG3452X
EAN: 6935364006471
Pieejamība: 2

460,66€

Bez PVN: 380,71€

Daudzums:

Produktu apskats
Specifikācija
Atsauksmes (0)

Manufacturer page

Atslēgvārdi: Switches

Specifikācijas

Specifikācija

Authentication Auto VLAN,Guest VLAN,MAC-based authentication,Port-based authentication

Authentication type AAA,RADIUS,TACACS+

BPDU filtering/protection Yes

Cloud-managed Yes

Configuring Location Settings (CLI) Yes

DHCP features DHCP client/DHCP relay/DHCP server

GARP VLAN Registration Protocol (GVRP) Yes

Head-of-line (HOL) blocking Yes

Huawei-proprietary MIB Y

IGMP proxy Yes

IP-MAC-Port binding Yes

IPv4 & IPv6 features IPv4/IPv6 access-control list (ACL)/IPv6 ping/IPv6 Telnet/IPv6 tracert

IPv4 routes 48

IPv6 routes 48

Loop protection Yes

Multicast Listener Discovery (MLD) snooping Y

Number of static routes 48

Product colour Black

Public MIB Y

Queue scheduling algorithms SP/Weighted Round Robin (WRR)/WRR+SP

Rack mount kit Yes

Rate limiting Yes

Static route Yes

Summary TP-Link Omada 48-Port Gigabit L2+ Managed Switch with 4 10GE SFP+ Slots. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48, Console port: RJ-45/Micro-USB. MAC address table: 16000 entries, Switching capacity: 176 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad. Power connector: AC-in jack. Rack mounting, Form factor: 1U

System event log Yes

Unit Calculated Volume 0.01875

Unit Calculated Weight 4.14

Units per Shipping Box 1

Virtual LAN features Private VLAN/Tagged VLAN/VLAN mapping/Voice VLAN

Pieslēgumi

10G support Yes

Basic switching RJ-45 Ethernet ports quantity 48

Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)

Specifikācijas

AC input frequency 50/60

AC input voltage 100 - 240

Access Control List (ACL) Yes

ARP inspection Yes

Augstums 44

Broadcast storm control Yes

Certification CE, FCC, RoHS

Console port RJ-45/Micro-USB

Dziļums 220

Flow control support Yes

Form factor 1U

Forwarding rate 130.9

Heat dissipation 111.65

IGMP snooping Yes

Jumbo frames 9000

Jumbo frames support Yes

Komplektā kabeļi AC

LED indicators Yes

Link aggregation Yes

MAC address filtering Yes

MAC address table 16000

Management protocols SNMPv1/v2c/v3, SNTP

MIB support RFC1213, RFC2233, RFC1643, RFC1493, RFC2674, RFC2819, RFC2021, RFC2620, RFC2618,

Modeļa nosaukums Omada 48-Port Gigabit L2+ Managed Switch with 4 10GE SFP+ Slots

Multicast support Yes

Networking standards IEEE 802.1D/IEEE 802.1Q/IEEE 802.1s/IEEE 802.1w/IEEE 802.3ad

Number of VLANs 4000

Operating relative humidity (H-H) 10 - 90

Operating temperature (T-T) 0 - 45

Package type Box

Packet buffer memory 12

Password protection Yes

Platums 440

Port mirroring Yes

Power connector AC-in jack

Power consumption (max) 32.72

Power over Ethernet (PoE) No

Power source AC

Power supply included Yes

Quality of Service (QoS) support Yes

Quick start guide Yes

Rack mounting Yes

Rack rails Yes

Series Omada

SFP+ module slots quantity 4

Spanning tree protocol Yes

SSH/SSL support Yes

Static port security Yes

Storage relative humidity (H-H) 5 - 90

Storage temperature (T-T) -40 - 70

Switch layer L2+

Switch type Managed

Switching capacity 176

VLAN support Yes

Web-based management Yes
