Zyxel GS1200-5HPV2-EU0101F

Zyxel GS1200-5HP v2 ? 5-Port Web Managed PoE+ Gigabit Switch

• 4 PoE+ ports (IEEE 802.3at), total power budget of 60 W
• User-friendly web-based management
• IGMP snooping v1/v2/v3 for efficient multicast traffic
• Supports VLAN and QoS for network segmentation and traffic control
• Link aggregation (1 LAG group: ports 3 & 4)
• Fanless, silent design ? ideal for offices and small business setups

Power and Network Control in One Simple Device
The Zyxel GS1200-5HP v2 combines Gigabit switching performance with PoE+ capabilities and web-based management. With up to 30 W per port (IEEE 802.3at) and a 60 W total power budget, it?s ideal for powering access points, IP cameras, and VoIP phones.

Perfect for Small Networks with PoE Needs
The switch intelligently detects PoE devices and provides reliable power. Via the web GUI, users can monitor PoE status and remotely reboot connected devices.

Intuitive Web Interface for Simple Setup
With built-in VLAN, QoS, and IGMP snooping support, the GS1200-5HP v2 gives users more control over their traffic with minimal configuration required.

Technical Specifications

• 5 x 10/100/1000 Mbps RJ-45 ports, 4 with PoE+ (IEEE 802.3at)
• Total PoE power budget: 60 W
• Switching capacity: 10 Gbps
• Forwarding rate: 7.44 Mpps
• Packet buffer: 128 KB
• MAC address table: 2K
• Jumbo frame support: 9 KB
• Features: Web management, VLAN, QoS, IGMP snooping, 1 LAG group (ports 3 & 4)
• Power consumption: max. 62.79 W / min. 0.935 W
• External power supply (100?240 V AC)
• Dimensions: 193 x 84 x 26 mm
• Weight: 392 g
