Mainboard, BIOSTAR, H610MHD D5, Intel H610, LGA 1700, micro ATX, RAM DDR5-SDRAM, 2xSlots, H610MHDD5
Popular
Mainboard, BIOSTAR, H610MHD D5, Intel H610, LGA 1700, micro ATX, RAM DDR5-SDRAM, 2xSlots, H610MHDD5
Mainboard, BIOSTAR, H610MHD D5, Intel H610, LGA 1700, micro ATX, RAM DDR5-SDRAM, 2xSlots, H610MHDD5
Mainboard, BIOSTAR, H610MHD D5, Intel H610, LGA 1700, micro ATX, RAM DDR5-SDRAM, 2xSlots, H610MHDD5
Mainboard, BIOSTAR, H610MHD D5, Intel H610, LGA 1700, micro ATX, RAM DDR5-SDRAM, 2xSlots, H610MHDD5
Reviews:
(0)
    Name:

    BIOSTAR H610MHD D5

  • Brand: BIOSTAR
  • Product Code: H610MHD D5
  • EAN: 4712960687745
  • Availability: 30
47.34€
Ex Tax: 39.12€
  • Product overview
  • Specification
  • Reviews (0)

Tags: Mainboards for Intel CPUs

Specifications
Specifikācija
1st M.2 highest PCI Express generation 3.0
1st M.2 largest key size 2280
Audio chip Realtek ALC897
Audio connector Yes
Clear CMOS jumper Yes
CPU fan connector Yes
ECC сompatibility Non-ECC
Front panel connector Yes
Motherboard chipset family Intel
Number of COM connectors 1
Number of CPU fan connectors 1
Number of EPS power connectors (8-pin) 1
Number of M.2 (M) slots 1
Number of SATA III connectors 4
Parallel processing technology support Not supported
PC health monitoring Fan/Temperature/Voltage
PCI Express x1 (Gen 3.x) slots 1
PCI Express x16 (Gen 4.x) slots 1
Product colour Black
Summary Biostar H610MHD D5. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processor series: Intel® Celeron®, Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i3 14th Gen, Intel.... Supported memory types: DDR5-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: PCI Express 3.0, SATA III, Supported storage drive types: HDD & SSD. USB connector type: USB Type-A. Ethernet interface type: Fast Ethernet, Gigabit Ethernet, LAN controller: Intel I219V
Supported memory clock speed (max) 5600
TPM connector Yes
Unit Calculated Volume 0.004256
Unit Calculated Weight 0.768
Units per Shipping Box 20
USB 3.2 Gen 1 (3.1 Gen 1) connectors 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2
Processor parameters
Compatible processor series Intel Core/Intel Core i3 12th Gen/Intel Core i3 13th Gen/Intel Core i3 14th Gen/Intel Core i5 12th Gen/Intel Core i5 13th Gen/Intel Core i5 14th Gen/Intel Core i7 12th Gen/Intel Core i7 13th Gen/Intel Core i7 14th Gen/Intel Core i9 12th Gen/Intel® Celeron®
Processor manufacturer Intel
Memory parameters
Maximum internal memory 128
Memory channels Dual-channel
Memory slots type DIMM
Memory type DDR5
Supported memory types DDR5-SDRAM
Unbuffered memory Yes
Storage parameters
Number of storage drives supported 5
Supported storage drive interfaces PCI Express 3.0,SATA III
Supported storage drive types HDD & SSD
Ports types
DVI-D ports quantity 1
HDMI ports quantity 1
Headphone outputs 3
Microphone in Yes
USB 2.0 connectors 2
USB 2.0 ports quantity 4
USB connector type USB Type-A
Connections types
Ethernet interface type Fast Ethernet/Gigabit Ethernet
Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 1
LAN controller Intel I219V
Wi-Fi No
Specifications
ATX Power connector (24-pin) Yes
Audio output channels 7.1
BIOS Type UEFI
Bundled software BullGuard
Cables included SATA
Chipset H610
Component for PC
Depth 208
DirectX version 12.0
Drivers included Yes
EPS power connector (8-pin) Yes
Form factor mATX
HDCP Yes
Model H610MHD D5
Motherboard chipset Intel H610
Motherboard form factor micro ATX
Number of memory slots 2
PS/2 ports quantity 1
Supported processor sockets LGA 1700
Width 236
Windows operating systems supported Windows 10 x64/Windows 11 x64
