Mainboard, MSI, AMD B650, SAM5, ATX, Memory DDR5, Memory slots 4, 1xPCI-Express 3.0 1x, 1xPCI-Express 4.0 2x, 1xPCI-Express 4.0 16x, 3xM.2, 1xHDMI, 1xDisplayPort, 2xUSB 2.0, 7xUSB 3.2, 1xUSB-C, 1xOptical S/PDIF, 1xRJ45, 3xAudio port, PROB650-AWIFI
Popular
- Brand: MSI
- Product Code: PRO B650-A WIFI
- EAN: 4711377246217
- Availability: 30
Name:
MSI PRO B650-A WIFI
165.60€
Ex Tax: 136.86€
- Product overview
- Specification
- Reviews (0)
Specifications
Specifikācija
1st M.2 highest PCI Express generation
5.0
1st M.2 largest key size
22110
2nd M.2 highest PCI Express generation
4.0
2nd M.2 largest key size
2580
3rd M.2 highest PCI Express generation
4.0
3rd M.2 largest key size
2280
ACPI version
6.4
Audio chip
Realtek ALC4080
BIOS memory size
256
Chassis intrusion connector
Y
CPU fan connector
Y
ECC ?ompatibility
non-ECC
Front panel audio connector
Y
Front panel connector
Y
Motherboard chipset family
AMD
Number of HDDs supported
9
Number of M.2 (M) slots
3
Number of SATA III connectors
6
On-board graphics card
N
Parallel processing technology support
Not supported
PCI Express x8 (Gen 3.x) slots
1
PCI Express x8 (Gen 4.x) slots
2
Product colour
Black
RGB LED pin header
Y
S/PDIF out port
Y
Summary
MSI PRO B650-A WIFI. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series. Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, Memory channels: Dual-channel. Supported storage drive interfaces: M.2, PCI Express, Supported storage drive types: HDD & SSD, RAID levels: 0, 5, 10. Ethernet interface type: 2.5 Gigabit Ethernet, Top Wi-Fi standard: Wi-Fi 6E (802.11ax), Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax). Component for: PC, Motherboard form factor: ATX, Motherboard chipset family: AMD
Supported memory clock speed (max)
7600
System Management BIOS (SMBIOS) version
3.4
Top Wi-Fi standard
Wi-Fi 6E (802.11ax)
TPM connector
Y
Unit Calculated Volume
0.008375
Unit Calculated Weight
2
Units per Shipping Box
5
USB 3.2 Gen 1 (3.1 Gen 1) connectors
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 2 (3.1 Gen 2) connectors
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
Processor parameters
Compatible processor series
AMD Ryzen 7000 Series/AMD Ryzen 8000 Series/AMD Ryzen 9000 Series
Processor manufacturer
AMD
Processor socket
AM5
Memory parameters
Maximum internal memory
256
Maximum internal memory supported by processor
256
Memory channels
Dual-channel
Memory type
DDR5
Supported memory clock speeds
4800/5000/5200/5400/5600/5800/6000/6200/6400/6600/6800/7000/7200/7400/7600
Supported memory types
DDR5-SDRAM
Unbuffered memory
Y
Storage parameters
Number of storage drives supported
6
RAID levels
0/10/5
RAID support
Y
Supported storage drive interfaces
M.2,PCI Express
Supported storage drive types
HDD & SSD
Ports types
DisplayPort version
1.4
DisplayPorts quantity
1
HDMI ports quantity
1
HDMI version
2.1
USB 2.0 connectors
4
Connections types
Bluetooth
Y
Bluetooth version
5.3
Ethernet interface type
2.5 Gigabit Ethernet
Ethernet LAN
Y
Ethernet LAN (RJ-45) ports
1
Wi-Fi
Y
Wi-Fi standards
802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)/Wi-Fi 6E (802.11ax)
Specifications
Audio output channels
7.1
BIOS Type
UEFI AMI
Cables included
SATA
Chipset
B650
Component for
PC
Depth
304.8
Form factor
ATX
Model
PRO B650-A WIFI
Motherboard chipset
AMD B650
Motherboard form factor
ATX
Number of memory slots
4
Supported processor sockets
Socket AM5
Width
243.84
Windows operating systems supported
Windows 10 x64/Windows 11 x64
