Mainboard, MSI, AMD B850, SAM5, Micro-ATX, Memory DDR5, Memory slots 4, PROB850M-PWIFI
Popular
Mainboard, MSI, AMD B850, SAM5, Micro-ATX, Memory DDR5, Memory slots 4, PROB850M-PWIFI
Mainboard, MSI, AMD B850, SAM5, Micro-ATX, Memory DDR5, Memory slots 4, PROB850M-PWIFI
Mainboard, MSI, AMD B850, SAM5, Micro-ATX, Memory DDR5, Memory slots 4, PROB850M-PWIFI
Mainboard, MSI, AMD B850, SAM5, Micro-ATX, Memory DDR5, Memory slots 4, PROB850M-PWIFI
Mainboard, MSI, AMD B850, SAM5, Micro-ATX, Memory DDR5, Memory slots 4, PROB850M-PWIFI
Reviews:
(0)
    Name:

    MSI PRO B850M-P WIFI

  • Brand: MSI
  • Product Code: PRO B850M-P WIFI
  • EAN: 4711377350181
  • Availability: 50
171.70€
Ex Tax: 141.90€
  • Product overview
  • Specification
  • Reviews (0)

Tags: Mainboards for AMD CPUs

Specifications
Specifikācija
1st M.2 highest PCI Express generation 5.0
1st M.2 largest key size 2280
2nd M.2 highest PCI Express generation 5.0
2nd M.2 largest key size 2280
3rd M.2 highest PCI Express generation 4.0
3rd M.2 largest key size 2280
ACPI version 6.5
Audio chip Realtek ALC897
BIOS memory size 256
CPU fan connector Y
ECC ?ompatibility non-ECC
Front panel audio connector Y
Front panel connector Y
Motherboard chipset family AMD
Number of CPU fan connectors 2
Number of HDDs supported 4
Number of M.2 (M) slots 3
Number of RGB LED pin headers 3
Number of SATA III connectors 4
Number of water pump connectors 1
On-board graphics card N
PCI Express x16 (Gen 3.x) slots 1
PCI Express x16 (Gen 4.x) slots 1
PCI Express x16 (Gen 5.x) slots 1
PCI Express x4 slots 1
Product colour Black
RGB LED pin header Y
Summary MSI PRO B850M-P WIFI. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series. Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 10. Ethernet interface type: 5 Gigabit Ethernet, Top Wi-Fi standard: Wi-Fi 7 (802.11be), Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E.... Component for: PC, Motherboard form factor: micro ATX, Motherboard chipset family: AMD
Supported memory clock speed (max) 8200
System Management BIOS (SMBIOS) version 3.7
Top Wi-Fi standard Wi-Fi 7 (802.11be)
Total number of SATA connectors 4
Unit Calculated Volume 0.006568
Unit Calculated Weight 1.41
Units per Shipping Box 10
USB 3.2 Gen 1 (3.1 Gen 1) connectors 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 2
Processor parameters
Compatible processor series AMD Ryzen 7000 Series/AMD Ryzen 8000 Series/AMD Ryzen 9000 Series
Processor manufacturer AMD
Processor socket AM5
Memory parameters
Maximum internal memory 256
Memory channels Dual-channel
Memory slots type DIMM
Memory type DDR5
Supported memory clock speeds 6000/6400/8200
Supported memory types DDR5-SDRAM
Storage parameters
Number of storage drives supported 7
RAID levels 0/1/10
RAID support Y
Supported storage drive interfaces M.2
Supported storage drive types HDD & SSD
Ports types
HDMI ports quantity 1
HDMI version 2.1
USB 2.0 connectors 4
Connections types
Bluetooth Y
Bluetooth version 5.4
Ethernet interface type 5 Gigabit Ethernet
Ethernet LAN Y
Ethernet LAN (RJ-45) ports 1
Wi-Fi Y
Wi-Fi standards 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)/Wi-Fi 6E (802.11ax)/Wi-Fi 7 (802.11be)
Specifications
ATX Power connector (24-pin) Y
Audio output channels 7.1
BIOS Type UEFI AMI
Chipset B850
Component for PC
Depth 243.84
Form factor mATX
Model PRO B850M-P WIFI
Motherboard chipset AMD B850
Motherboard form factor Micro ATX
Number of memory slots 4
PCI Express x16 slots 1
Supported processor sockets Socket AM5
Width 243.84
Windows operating systems supported Windows 11 x64
