NET VIDEO RECORDER 4CH 4POE/NVR4104-P-4KS3 DAHUA

Популярный

Отзывы:

(0)

Наименование:

DAHUA DHI-NVR4104-P-4KS3

Бренд: DAHUA
Модель: DHI-NVR4104-P-4KS3
EAN: 6923172573797
Наличие: 3

256.35€

Без PVN: 211.86€

Кол-во:

Обзор товара
Характеристики
Отзывы (0)

Manufacturer page

Характеристики

Specifikācija

Audio RCA inputs 1

Audio RCA outputs 1

Backup function Yes

eSATA ports quantity 1

HDD interface SATA

Input bandwidth 80

Multi-screen Yes

Output bandwidth 60

Product colour White

Rack capacity 1U

Summary Dahua Technology Lite NVR4104-P-4KS3. Video input channels: 4 channels, Maximum resolution: 3840 x 2160 pixels, Video recording modes: 720p, 960p, 1080p. Maximum storage capacity: 20 TB, HDD interface: SATA. Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.3af, IEEE 802.3at, Supported network protocols: HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP;.... Rack capacity: 1U, Product colour: White, Certification: CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021;.... Power consumption (max): 25.5 W, Power consumption (typical): 10 W, Output current: 1.22 A

Unit Calculated Volume 0.009015

Units per Shipping Box 1

Video motion detection Yes

Процессор

Built-in processor Yes

Запоминающее устройство

Maximum storage capacity 20

Порты

USB 2.0 ports quantity 2

VGA (D-Sub) output ports 1

Количество портов HDMI 1

Подключения

Ethernet LAN data rates 10/100

Wi-Fi No

Порты локальной сети Ethernet (RJ-45) 1

Камера

Video recording modes 1080p/720p/960p

Спецификация

Audio formats supported G.711 µ-law/G.711 A-law/G.726/PCM

Browser supported Chrome; IE; Safari; Edge; Firefox

Certification CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014 CE-LVD: EN 62368-1:2014

Face detection Yes

Image formats supported MJPEG

Maximum resolution 3840 x 2160

Mobile operating systems supported Android/iOS

Model DHI-NVR4104-P-4KS3

Networking standards IEEE 802.3af/IEEE 802.3at

Operating relative humidity (H-H) 10 - 93

Operating system installed Embedded LINUX

Operating temperature (T-T) -10 - 55

Output current 1.22

Output voltage 53

Package depth 96

Package height 261

Package weight 1380

Package width 364

Power consumption (max) 25.5

Power consumption (typical) 10

Power over Ethernet (PoE) Yes

Power over Ethernet (PoE) ports quantity 4

Rack mounting Yes

Storage temperature (T-T) -20 - 60

Supported network protocols HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.)

Supported resolutions 1 HDMI, 1 VGA Simultaneous: HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 Heterogeneous: HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720

Total Power over Ethernet (PoE) budget 36

Video formats supported H.264/H.264+/H.265/H.265+

Video input channels 4

Weight 500

Высота 45.6

Глубина 206.4

Название модели NVR4104-P-4KS3

Ширина 204.6
