Power Supply, GIGABYTE, UD850GM PG5 V2, ATX 3.1, 850 Watts, Efficiency 80 PLUS GOLD, PFC Active, MTBF 100000 hours, GP-UD850GMPG5V2
Power Supply, GIGABYTE, UD850GM PG5 V2, ATX 3.1, 850 Watts, Efficiency 80 PLUS GOLD, PFC Active, MTBF 100000 hours, GP-UD850GMPG5V2
Power Supply, GIGABYTE, UD850GM PG5 V2, ATX 3.1, 850 Watts, Efficiency 80 PLUS GOLD, PFC Active, MTBF 100000 hours, GP-UD850GMPG5V2
Power Supply, GIGABYTE, UD850GM PG5 V2, ATX 3.1, 850 Watts, Efficiency 80 PLUS GOLD, PFC Active, MTBF 100000 hours, GP-UD850GMPG5V2
Power Supply, GIGABYTE, UD850GM PG5 V2, ATX 3.1, 850 Watts, Efficiency 80 PLUS GOLD, PFC Active, MTBF 100000 hours, GP-UD850GMPG5V2
Power Supply, GIGABYTE, UD850GM PG5 V2, ATX 3.1, 850 Watts, Efficiency 80 PLUS GOLD, PFC Active, MTBF 100000 hours, GP-UD850GMPG5V2
Power Supply, GIGABYTE, UD850GM PG5 V2, ATX 3.1, 850 Watts, Efficiency 80 PLUS GOLD, PFC Active, MTBF 100000 hours, GP-UD850GMPG5V2
Power Supply, GIGABYTE, UD850GM PG5 V2, ATX 3.1, 850 Watts, Efficiency 80 PLUS GOLD, PFC Active, MTBF 100000 hours, GP-UD850GMPG5V2
Power Supply, GIGABYTE, UD850GM PG5 V2, ATX 3.1, 850 Watts, Efficiency 80 PLUS GOLD, PFC Active, MTBF 100000 hours, GP-UD850GMPG5V2
Reviews:
(0)
    Name:

    Gigabyte GP-UD850GM PG5 V2

  • Brand: Gigabyte
  • Product Code: GP-UD850GM PG5 V2
  • EAN: 4719331555993
  • Availability: 50
99.06€
Ex Tax: 81.87€
  • Product overview
  • Specification
  • Reviews (0)

Tags: Desktop PC PSU

Specifications
Specifikācija
Cabling type Fully-Modular
CPU power cable length 600
Hold time 16
Motherboard power cable length 610
Number of EPS connectors 2
PCI Express power cable length 700
PCI Express power connectors (16-pin) 1
Peripheral (Molex) power cable length 150/500
Power supply unit (PSU) form factor ATX
Product colour Black
Purpose PC
SATA power cable length 150/600
Summary GIGABYTE UD850GM PG5 V2 Power Supply Unit- PCIe Gen 5.1, 80 PLUS Gold, Fully Modular Design, 120mm Fan, ATX 3.1 compatible, EU Plug. Total power: 850 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 61 cm, SATA power cable length: 150,600 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 150 mm, Depth: 140 mm, Height: 86 mm
Unit Calculated Volume 0.007678
Unit Calculated Weight 2.58
Units per Shipping Box 5
Warranty period 10
Processor parameters
CPU power connector (4+4 pin) Yes
Storage parameters
Number of SATA power connectors 8
Specifications
80 PLUS certification 80 PLUS Gold
AC input frequency 50/60
AC input voltage 100 - 240
ATX version 3.1
Bearing technology HYB
Combined power (+12V) 850
Combined power (+3.3V) 105
Combined power (+5V) 105
Combined power (+5Vsb) 15
Combined power (-12V) 3.6
Cooling type Active
Depth 140
Efficiency 90
Fan diameter 120
Floppy drive power connector 1
Height 86
Input current 12 - 6
Max output current (+12V) 70.8
Max output current (+3.3V) 20
Max output current (+5V) 20
Max output current (+5Vsb) 3
Max output current (-12V) 0.3
Mean time between failures (MTBF) 100000
Model name UD850GM PG5 V2
Motherboard power connector 20+4 pin ATX
Number of fans 1
On/off switch Yes
Package depth 269
Package height 211
Package type Box
Package weight 2560
Package width 618
PCI Express connector Yes
PCI Express power connectors (6+2 pin) 4
Peripheral (Molex) power connectors (4-pin) 3
Power factor 0.9
Power Factor Correction (PFC) type Active
Power protection features Over current/Over power/Over voltage/Overheating/Short circuit/Under voltage
Total power 850
Weight 2400
Width 150
