Mainboard, ASUS, AMD B650, Micro-ATX, Memory DDR5, Memory slots 4, 3xPCI-Express 4.0 16x, 2xM.2, 1x15pin D-sub, 1xHDMI, 1xDisplayPort, 4xUSB 2.0, 4xUSB 3.2, 1xPS/2, 1xRJ45, 3xAudio port, PRIMEB650M-AWIFIII

Популярный

Отзывы:

(0)

Наименование:

Asus PRIMEB650M-AWIFIII

Бренд: Asus
Модель: PRIMEB650M-AWIFIII
EAN: 4711387034934
Наличие: 6

141.78€

Без PVN: 117.17€

Кол-во:

Обзор товара
Характеристики
Отзывы (0)

Manufacturer page

Характеристики

Specifikācija

12V power connector Yes

Audio connector Yes

BIOS memory size 256

Clear CMOS button Yes

CPU fan connector Yes

ECC сompatibility ECC & Non-ECC

Front panel connector Yes

Motherboard chipset family AMD

Number of chassis fan connectors 3

Number of COM connectors 1

Number of HDDs supported 4

PCI Express x16 (Gen 4.x) slots 3

Power fan connector Yes

RGB LED pin header Yes

S/PDIF out connector Yes

Summary ASUS PRIME B650M-A WIFI II. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processor series: AMD Ryzen™ 7. Supported memory types: DDR5-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, PCI Express 4.0, PCI Express 5.0, SATA, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 10. USB connector type: USB Type-A. Ethernet interface type: 2.5 Gigabit Ethernet, Top Wi-Fi standard: Wi-Fi 6 (802.11ax), Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)

Top Wi-Fi standard Wi-Fi 6 (802.11ax)

Total number of SATA connectors 4

TPM connector Yes

Unit Calculated Volume 0.005488

Unit Calculated Weight 1.41

Units per Shipping Box 1

USB 3.2 Gen 1 (3.1 Gen 1) connectors 2

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 2

Процессор

Compatible processor series AMD Ryzen™ 7

Processor manufacturer AMD

Сокет процессора AM5

Память

Maximum internal memory 128

Memory channels Dual-channel

Memory slots type DIMM

Supported memory clock speeds 4800/5000/5200/5400/5600/5800/6000/6200/6400

Supported memory types DDR5-SDRAM

Unbuffered memory Yes

Тип памяти DDR5

Запоминающее устройство

Number of SATA connectors 4

Number of storage drives supported 2

RAID levels 0/1/10

RAID support Yes

Supported storage drive interfaces M.2,PCI Express 4.0,PCI Express 5.0,SATA

Supported storage drive types HDD & SSD

Порты

DisplayPorts quantity 1

Headphone outputs 1

Microphone in Yes

USB 2.0 connectors 2

USB 2.0 ports quantity 4

USB connector type USB Type-A

Количество портов HDMI 1

Количество портов VGA (D-Sub) 1

Подключения

Bluetooth Yes

Ethernet interface type 2.5 Gigabit Ethernet

Ethernet LAN Yes

Wi-Fi Yes

Wi-Fi standards 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)

Версия Bluetooth 5.2

Порты локальной сети Ethernet (RJ-45) 1

Спецификация

ATX Power connector (24-pin) Yes

Audio output channels 7.1

BIOS Type UEFI AMI

Bundled software ASUS Exclusive SoftwareArmoury Crate- Aura Creator- Aura Sync- Fan Xpert 2+- Power SavingAI Suite 3- TurboV EVO- DIGI+ VRM- PC CleanerASUS CPU-ZMyASUSNorton Anti-virus software (Free Trial version)WinRARUEFI BIOSASUS EZ DIY- ASUS CrashFree

Component for PC

EPS power connector (8-pin) Yes

Form factor mATX

Line-in Yes

Model PRIME B650M-A WIFI II

Motherboard chipset AMD B650

Motherboard form factor micro ATX

Number of memory slots 4

Peripheral (Molex) power connectors (4-pin) 4

Power source type ATX

Windows operating systems supported Windows 10/Windows 11

Глубина 244

Кабели в комплекте SATA

Чипсет B650

Ширина 244
