Mainboard, ASUS, AMD B650, SAM5, Micro-ATX, Memory DDR5, Memory slots 4, 2xPCI-Express 4.0 1x, 1xPCI-Express 4.0 16x, 2xM.2, 1xHDMI, 2xDisplayPort, 4xUSB 2.0, 2xUSB 3.2, 2xUSB-C, 1xRJ45, 3xAudio port, TUFGAMINGB650M-EWIFI

Популярный

Последнее

Mainboard, ASUS, AMD B650, SAM5, Micro-ATX, Memory DDR5, Memory slots 4, 2xPCI-Express 4.0 1x, 1xPCI-Express 4.0 16x, 2xM.2, 1xHDMI, 2xDisplayPort, 4xUSB 2.0, 2xUSB 3.2, 2xUSB-C, 1xRJ45, 3xAudio port, TUFGAMINGB650M-EWIFI

Отзывы:

(0)

Наименование:

Asus TUFGAMINGB650M-EWIFI

Бренд: Asus
Модель: TUFGAMINGB650M-EWIFI
EAN: 4711387222041
Наличие: 1

169.79€

Без PVN: 140.32€

Кол-во:

Обзор товара
Характеристики
Отзывы (0)

Manufacturer page

Характеристики

Specifikācija

12V power connector Yes

BIOS memory size 256

CPU fan connector Yes

ECC сompatibility ECC & Non-ECC

Front panel audio connector Yes

Motherboard chipset family AMD

Number of chassis fan connectors 2

Number of HDDs supported 4

Number of M.2 (M) slots 2

Number of SATA III connectors 4

PCI Express x1 (Gen 4.x) slots 2

RGB LED pin header Yes

Summary ASUS TUF GAMING B650M-E WIFI. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processor series: AMD Ryzen 7000 Series. Supported memory types: DDR5-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 10. Ethernet interface type: 2.5 Gigabit Ethernet, Gigabit Ethernet, Top Wi-Fi standard: Wi-Fi 6 (802.11ax), Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax). Component for: PC, Motherboard form factor: micro ATX, Motherboard chipset family: AMD

Top Wi-Fi standard Wi-Fi 6 (802.11ax)

Unit Calculated Volume 0.006327

Unit Calculated Weight 1.72

Units per Shipping Box 10

USB 3.2 Gen 1 (3.1 Gen 1) connectors 2

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 1

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 1

Процессор

Compatible processor series AMD Ryzen 7000 Series

Processor manufacturer AMD

Сокет процессора AM5

Память

Maximum internal memory 128

Memory channels Dual-channel

Memory slots type DIMM

Supported memory clock speeds 4800/5000/5200/5400/5600/5800/6000/6200/6400

Supported memory types DDR5-SDRAM

Unbuffered memory Yes

Тип памяти DDR5

Запоминающее устройство

Number of storage drives supported 6

RAID levels 0/1/10

RAID support Yes

Supported storage drive interfaces M.2,SATA III

Supported storage drive types HDD & SSD

Порты

DisplayPorts quantity 2

Microphone in Yes

USB 2.0 connectors 2

USB 2.0 ports quantity 4

Количество портов HDMI 1

Подключения

Bluetooth Yes

Ethernet interface type 2.5 Gigabit Ethernet/Gigabit Ethernet

Ethernet LAN Yes

Wi-Fi Yes

Wi-Fi standards 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)

Версия Bluetooth 5.2

Порты локальной сети Ethernet (RJ-45) 1

Спецификация

ATX Power connector (24-pin) Yes

Audio output channels 7.1

BIOS Type UEFI AMI

Component for PC

EPS power connector (8-pin) Yes

Form factor mATX

Model TUF GAMING B650M-E WIFI

Motherboard chipset AMD B650

Motherboard form factor micro ATX

Number of memory slots 4

Package depth 275

Package height 67.4

Package weight 1699.7

Package width 275

PS/2 ports quantity 1

Weight 1007

Windows operating systems supported Windows 10 x64/Windows 11

Высота 50

Глубина 244

Кабели в комплекте SATA

Чипсет B650

Ширина 244
