Mainboard, ASUS, Intel B860 Express, LGA1851, Micro-ATX, Memory DDR5, Memory slots 4, 1xPCI-Express 4.0 1x, 1xPCI-Express 4.0 16x, 1xPCI-Express 5.0 16x, 2xM.2, 1xHDMI, 1xDisplayPort, 7xUSB 2.0, 1xUSB-C, 1xUSB-C w/Thunderbolt, 1xOptical S/PDIF, 1xRJ45, 3x

Популярный

Отзывы:

(0)

Наименование:

Asus PRIME B860M-A WIFI

Бренд: Asus
Модель: PRIME B860M-A WIFI
EAN: 4711387806289
Наличие: 5

197.91€

Без PVN: 163.56€

Кол-во:

Обзор товара
Характеристики
Отзывы (0)

Manufacturer page

Характеристики

Specifikācija

12V power connector Yes

1st M.2 highest PCI Express generation 5.0

1st M.2 largest key size 2280

2nd M.2 highest PCI Express generation 4.0

2nd M.2 largest key size 2280

Antenna included Yes

BIOS memory size 256

Chassis intrusion connector Yes

CPU fan connector Yes

ECC сompatibility Non-ECC

Front panel audio connector Yes

Front panel connector Yes

Motherboard chipset family Intel

Number of chassis fan connectors 3

Number of COM connectors 1

Number of HDDs supported 4

Number of M.2 (M) slots 2

Number of SATA III connectors 4

Parallel processing technology support Not supported

PCI Express x1 (Gen 4.x) slots 1

PCI Express x16 (Gen 4.x) slots 1

PCI Express x16 (Gen 5.x) slots 1

RGB LED pin header Yes

S/PDIF out connector Yes

Screws included Yes

Summary ASUS PRIME B860M-A WIFI. Processor manufacturer: Intel, Processor socket: LGA 1851 (Socket V1), Compatible processor series: Intel Core Ultra (Series 2). Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Ethernet interface type: 2.5 Gigabit Ethernet, Top Wi-Fi standard: Wi-Fi 6E (802.11ax), Wi-Fi standards: Wi-Fi 6E (802.11ax). Component for: PC, Motherboard form factor: micro ATX, Motherboard chipset family: Intel

Thunderbolt headers 1

Top Wi-Fi standard Wi-Fi 6E (802.11ax)

TPM connector Yes

Unit Calculated Volume 0.00622

Unit Calculated Weight 1.48

Units per Shipping Box 10

USB 3.2 Gen 1 (3.1 Gen 1) connectors 1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2

USB 3.2 Gen 2 (3.1 Gen 2) connectors 1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 1

USB 3.2 Gen 2x2 Type-C ports quantity 1

WiFi-AP antenna jack 1

Процессор

Compatible processor series Intel Core Ultra (Series 2)

Processor manufacturer Intel

Память

Maximum internal memory 256

Memory channels Dual-channel

Memory slots type DIMM

Supported memory types DDR5-SDRAM

Unbuffered memory Yes

Тип памяти DDR5

Запоминающее устройство

Number of storage drives supported 6

RAID levels 0/1/10/5

RAID support Yes

Supported storage drive interfaces M.2,SATA III

Supported storage drive types HDD & SSD

Порты

DisplayPorts quantity 2

USB 2.0 connectors 1

USB 2.0 ports quantity 4

Количество портов HDMI 1

Подключения

Bluetooth Yes

Ethernet interface type 2.5 Gigabit Ethernet

Ethernet LAN Yes

Wi-Fi Yes

Wi-Fi standards Wi-Fi 6E (802.11ax)

Версия Bluetooth 5.3

Порты локальной сети Ethernet (RJ-45) 1

Спецификация

ATX Power connector (24-pin) Yes

Audio output channels 7.1

BIOS Type UEFI AMI

Component for PC

Form factor mATX

Model PRIME B860M-A WIFI

Motherboard chipset Intel B860

Motherboard form factor micro ATX

Number of memory slots 4

Package depth 275

Package height 67.5

Package weight 1440

Package width 275

Supported processor sockets LGA 1851

Windows operating systems supported Windows 10 x64/Windows 11

Глубина 244

Кабели в комплекте SATA

Чипсет B860

Ширина 244
