Mainboard, ASUS, Intel H610, LGA 1700, micro ATX, RAM DDR5-SDRAM, 2xSlots, Wi-Fi Yes, Bluetooth Yes, 2xNumber of M.2 (M) slots, PRIMEH610M-AWIFI
Mainboard, ASUS, Intel H610, LGA 1700, micro ATX, RAM DDR5-SDRAM, 2xSlots, Wi-Fi Yes, Bluetooth Yes, 2xNumber of M.2 (M) slots, PRIMEH610M-AWIFI
Mainboard, ASUS, Intel H610, LGA 1700, micro ATX, RAM DDR5-SDRAM, 2xSlots, Wi-Fi Yes, Bluetooth Yes, 2xNumber of M.2 (M) slots, PRIMEH610M-AWIFI
Mainboard, ASUS, Intel H610, LGA 1700, micro ATX, RAM DDR5-SDRAM, 2xSlots, Wi-Fi Yes, Bluetooth Yes, 2xNumber of M.2 (M) slots, PRIMEH610M-AWIFI
Mainboard, ASUS, Intel H610, LGA 1700, micro ATX, RAM DDR5-SDRAM, 2xSlots, Wi-Fi Yes, Bluetooth Yes, 2xNumber of M.2 (M) slots, PRIMEH610M-AWIFI
Mainboard, ASUS, Intel H610, LGA 1700, micro ATX, RAM DDR5-SDRAM, 2xSlots, Wi-Fi Yes, Bluetooth Yes, 2xNumber of M.2 (M) slots, PRIMEH610M-AWIFI
Mainboard, ASUS, Intel H610, LGA 1700, micro ATX, RAM DDR5-SDRAM, 2xSlots, Wi-Fi Yes, Bluetooth Yes, 2xNumber of M.2 (M) slots, PRIMEH610M-AWIFI
Mainboard, ASUS, Intel H610, LGA 1700, micro ATX, RAM DDR5-SDRAM, 2xSlots, Wi-Fi Yes, Bluetooth Yes, 2xNumber of M.2 (M) slots, PRIMEH610M-AWIFI
Отзывы:
(0)
    Наименование:

    Asus PRIME H610M-A WIFI

  • Бренд: Asus
  • Модель: PRIME H610M-A WIFI
  • EAN: 4711387301777
  • Наличие: 30
123.73€
Без PVN: 102.26€
  • Обзор товара
  • Характеристики
  • Отзывы (0)

Mainboards for Intel CPUs

Характеристики
Specifikācija
12V power connector Yes
Audio connector Yes
BIOS memory size 128
Clear CMOS button Yes
CPU fan connector Yes
ECC сompatibility Non-ECC
Front panel audio connector Yes
Motherboard chipset family Intel
Number of chassis fan connectors 2
Number of COM connectors 1
Number of HDDs supported 4
Number of M.2 (M) slots 2
Number of SATA III connectors 4
Parallel processing technology support Not supported
PCI Express x1 (Gen 3.x) slots 1
PCI Express x16 (Gen 4.x) slots 1
RGB LED pin header Yes
S/PDIF out connector Yes
Summary ASUS PRIME H610M-A WIFI. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processor series: Intel® Celeron®, Intel® Pentium® Gold, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™.... Supported memory types: DDR5-SDRAM, Maximum internal memory: 96 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD. Ethernet interface type: Gigabit Ethernet, Top Wi-Fi standard: Wi-Fi 5 (802.11ac), Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac). Component for: PC, Motherboard form factor: micro ATX, Motherboard chipset family: Intel
Supported memory clock speed (max) 5600
Top Wi-Fi standard Wi-Fi 5 (802.11ac)
TPM connector Yes
Unit Calculated Volume 0.00471
Unit Calculated Weight 1.09
Units per Shipping Box 10
USB 3.2 Gen 1 (3.1 Gen 1) connectors 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 1
WiFi-AP antenna jack 1
Процессор
Compatible processor series Intel® Celeron®/Intel® Core™ i3/Intel® Core™ i5/Intel® Core™ i7/Intel® Core™ i9/Intel® Pentium® Gold
Processor manufacturer Intel
Память
Maximum internal memory 96
Memory channels Dual-channel
Memory slots type DIMM
Supported memory clock speeds 4800/5000/5200/5400/5600
Supported memory types DDR5-SDRAM
Unbuffered memory Yes
Тип памяти DDR5
Запоминающее устройство
Number of storage drives supported 6
Supported storage drive interfaces M.2,SATA III
Supported storage drive types HDD & SSD
Порты
DisplayPort version 1.4
DisplayPorts quantity 1
HDMI version 2.1
Headphone outputs 1
Microphone in Yes
USB 2.0 connectors 2
USB 2.0 ports quantity 4
Количество портов HDMI 1
Количество портов VGA (D-Sub) 1
Подключения
Bluetooth Yes
Ethernet interface type Gigabit Ethernet
Ethernet LAN Yes
Wi-Fi Yes
Wi-Fi standards 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)
Версия Bluetooth 5.0
Порты локальной сети Ethernet (RJ-45) 1
Спецификация
ATX Power connector (24-pin) Yes
Audio output channels 7.1
BIOS Type UEFI AMI
Component for PC
EPS power connector (8-pin) Yes
Form factor mATX
Line-in Yes
Motherboard chipset Intel H610
Motherboard form factor micro ATX
Number of memory slots 2
Package depth 263
Package height 51.5
Package weight 1072
Package width 270
PS/2 ports quantity 2
Supported processor sockets LGA 1700
Windows operating systems supported Windows 10 x64/Windows 11 x64
Глубина 216
Кабели в комплекте SATA
Чипсет H610
Ширина 244
