Mainboard, ASUS, Intel H610, LGA1700, Micro-ATX, Memory DDR5, Memory slots 2, 1xPCI-Express 3.0 1x, 1xPCI-Express 4.0 16x, 1xM.2, 1x15pin D-sub, 1xHDMI, 4xUSB 2.0, 2xUSB 3.2, 1xPS/2, 1xRJ45, 3xAudio port, PRIMEH610M-K

Популярный

Отзывы:

(0)

Наименование:

Asus PRIMEH610M-K

Бренд: Asus
Модель: PRIMEH610M-K
EAN: 4711387336328
Наличие: 100

71.35€

Без PVN: 58.97€

Кол-во:

Обзор товара
Характеристики
Отзывы (0)

Manufacturer page

Характеристики

Specifikācija

12V power connector Yes

BIOS memory size 128

Clear CMOS jumper Yes

CPU fan connector Yes

ECC ?ompatibility Non-ECC

Front panel audio connector Yes

Motherboard chipset family Intel

Number of chassis fan connectors 2

Number of COM connectors 1

Number of HDDs supported 4

Number of M.2 (M) slots 1

Number of SATA III connectors 4

PCI Express x1 (Gen 3.x) slots 1

PCI Express x16 (Gen 4.x) slots 1

Product colour Multicolour

Product Net Weight 0.62

RGB LED pin header Yes

S/PDIF out connector Yes

Summary ASUS Prime H610M-K. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processor series: Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9,.... Supported memory types: DDR5-SDRAM, Maximum internal memory: 96 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD. USB connector type: USB Type-A. Ethernet interface type: Gigabit Ethernet

TPM connector Yes

Unit Calculated Volume 0.004915

Unit Calculated Weight 0.95

Units per Shipping Box 10

USB 3.2 Gen 1 (3.1 Gen 1) connectors 1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2

Процессор

Compatible processor series Intel Celeron/Intel Core i3/Intel Core i5/Intel Core i7/Intel Core i9/Intel Pentium Gold

Processor manufacturer Intel

Память

Maximum internal memory 96

Memory channels Dual-channel

Memory slots type DIMM

Supported memory clock speeds 4800/5000/5200/5400/5600

Supported memory types DDR5-SDRAM

Unbuffered memory Yes

Тип памяти DDR5

Запоминающее устройство

Number of storage drives supported 5

Supported storage drive interfaces M.2,SATA III

Supported storage drive types HDD & SSD

Порты

Headphone outputs 1

Microphone in Yes

USB 2.0 connectors 1

USB 2.0 ports quantity 4

USB connector type USB Type-A

Количество портов HDMI 1

Количество портов VGA (D-Sub) 1

Подключения

Ethernet interface type Gigabit Ethernet

Ethernet LAN Yes

Wi-Fi No

Порты локальной сети Ethernet (RJ-45) 1

Спецификация

ATX Power connector (24-pin) Yes

Audio output channels 7.1

BIOS Type UEFI AMI

Component for PC

EPS power connector (8-pin) Yes

Form factor mATX

Line-in Yes

Model PRIME H610M-K

Motherboard chipset Intel H610

Motherboard form factor micro ATX

Number of memory slots 2

Package depth 263

Package height 51.5

Package weight 820

Package width 270

PS/2 ports quantity 1

Weight 470

Windows operating systems supported Windows 10 x64/Windows 11

Высота 36.5

Глубина 203

Кабели в комплекте SATA

Чипсет H610

Ширина 234
