Mainboard, GIGABYTE, AMD X870, SAM5, ATX, Memory DDR5, Memory slots 4, X870AELITEWIFI71.1
Популярный
- Бренд: Gigabyte
- Модель: X870 A ELITE WIFI7 1.1
- EAN: 4719331864811
- Наличие: 9
Наименование:
Gigabyte X870 A ELITE WIFI7 1.1
282.74€
Без PVN: 233.67€
- Обзор товара
- Характеристики
- Отзывы (0)
Характеристики
Specifikācija
1st M.2 highest PCI Express generation
5.0
1st M.2 largest key size
25110
2nd M.2 highest PCI Express generation
5.0
2nd M.2 largest key size
22110
3rd M.2 highest PCI Express generation
5.0
3rd M.2 largest key size
22110
4th M.2 highest PCI Express generation
4.0
4th M.2 largest key size
22110
ACPI version
5.0
Antenna included
Да
Audio chip
Realtek ALC1220
BIOS memory size
256
Clear CMOS button
Да
Clear CMOS jumper
Да
CPU fan connector
Да
Desktop Management Interface (DMI) version
2.7
ECC ?ompatibility
Non-ECC
Front panel audio connector
Да
Front panel connector
Да
Lithium weight per battery
0.07
Maximum internal memory per slot
64
Motherboard chipset family
AMD
Number of chassis fan connectors
6
Number of CPU fan connectors
2
Number of EPS power connectors (8-pin)
2
Number of HDDs supported
4
Number of M.2 (M) slots
4
Number of RGB LED pin headers
4
Number of SATA III connectors
4
Number of water pump connectors
3
On-board graphics card
Нет
Parallel processing technology support
Не поддерживается
PC health monitoring
Вентилятор/Напряжение/Температура
PCI Express x16 (Gen 3.x) slots
1
PCI Express x16 (Gen 4.x) slots
1
PCI Express x16 (Gen 5.x) slots
1
PCI Express x4 slots
2
Product colour
Черный
Products per shipping (inner) case
1
RGB LED pin header
Да
S/PDIF out port
Да
Screws included
Да
Summary
GIGABYTE X870 AORUS ELITE WIFI7. Производитель процессора: AMD, Сокет процессора: Socket AM5, Совместимые серии процессоров: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series. Поддерживаемые типы памяти: DDR5-SDRAM, Максимальная внутренняя память: 256 GB, Тип слотов памяти: DIMM. Поддерживаемые интерфейсы носителя: M.2, SATA III, Поддерживаемые типы накопителей: HDD & SSD, Уровни RAID: 0, 1, 10. Тип Ethernet интерфейса: 2.5 Gigabit Ethernet, Контроллер LAN: Realtek RTL8125, Основной стандарт Wi-Fi: Wi-Fi 7 (802.11be). Комплектующие для: ПК, Формат материнской платы: ATX, Семейство чипсета материнской платы: AMD
Supported memory clock speed (max)
8200
System Management BIOS (SMBIOS) version
2.7
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
TPM connector
Да
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
3
USB 3.2 Gen 2x2 connectors
1
USB4 Gen 2x2 ports quantity
2
Warranty period
3
WiFi-AP antenna jack
2
WLAN controller model
MediaTek MT7925
Вес в упаковке
2.2
Количество в транспортной упаковке
1
Модель
X870 AORUS ELITE WIFI7
Объем
0.007344
Процессор
Compatible processor series
AMD Ryzen 7000 Series/AMD Ryzen 8000 Series/AMD Ryzen 9000 Series
Processor manufacturer
AMD
Сокет процессора
AM5
Память
Maximum internal memory
256
Maximum internal memory supported by processor
256
Memory channels
Dual-channel
Memory slots type
DIMM
Supported memory clock speeds
4400/4800/5200/5600/6000/6200/6400/6600/6666/6800/7000/7200/7600/7800/8000/8200
Supported memory module capacities
16GB/1GB/24GB/2GB/32GB/4GB/8GB
Supported memory types
DDR5-SDRAM
Тип памяти
DDR5
Запоминающее устройство
Number of storage drives supported
8
RAID levels
0/1/10
RAID support
Да
Supported storage drive interfaces
M.2,SATA III
Supported storage drive types
HDD & SSD
Порты
DisplayPort version
1.4
DisplayPorts quantity
2
HDMI version
2.1
Headphone outputs
1
Microphone in
Да
USB 2.0 connectors
2
USB 2.0 ports quantity
2
Количество портов HDMI
1
Подключения
Bluetooth
Да
Ethernet interface type
2.5 Gigabit Ethernet
Ethernet LAN
Да
LAN controller
Realtek RTL8125
Wi-Fi
Да
Wi-Fi standards
Wi-Fi 7 (802.11be)
Версия Bluetooth
5.4
Порты локальной сети Ethernet (RJ-45)
1
Батарея
Batteries included
Да
Battery type
CR2032
Battery weight
3
Количество ячеек батареи
1
Технология аккумуляторов
Lithium-Manganese Dioxide (LiMnO2)
Спецификация
ATX Power connector (24-pin)
Да
Audio output channels
7.1
BIOS Type
UEFI AMI
Bundled software
Norton® Internet Security (OEM version)LAN bandwidth management software
Component for
ПК
Country of origin
Китай
DirectX version
12.0
EPS power connector (8-pin)
Да
Form factor
ATX
Motherboard chipset
AMD X870
Motherboard form factor
ATX
Number of memory slots
4
Package depth
270
Package height
80
Package weight
2740
Package width
335
Supported processor sockets
Socket AM5
Weight
2400
Windows operating systems supported
Windows 11 x64
Высота
35
Глубина
244
Чипсет
X870
Ширина
305
