    Наименование:

    Gigabyte X870 A ELITE WF7 ICE 1.1

  • Бренд: Gigabyte
  • Модель: X870 A ELITE WF7 ICE 1.1
  • EAN: 4719331864682
  • Наличие: 13
285.91€
Без PVN: 236.29€
  • Обзор товара
  • Характеристики
  • Отзывы (0)

Mainboards for AMD CPUs

Характеристики
Specifikācija
12V power connector Yes
1st M.2 highest PCI Express generation 5.0
1st M.2 largest key size 25110
2nd M.2 highest PCI Express generation 5.0
2nd M.2 largest key size 22110
3rd M.2 highest PCI Express generation 5.0
3rd M.2 largest key size 22110
4th M.2 highest PCI Express generation 4.0
4th M.2 largest key size 22110
ACPI version 5.0
Antenna included Yes
Audio chip Realtek ALC1220
BIOS memory size 256
Clear CMOS button Yes
Clear CMOS jumper Yes
CPU fan connector Yes
Desktop Management Interface (DMI) version 2.7
Discrete graphics support Yes
ECC сompatibility Non-ECC
Front panel audio connector Yes
Front panel connector Yes
Lithium weight per battery 0.07
Maximum internal memory per slot 64
Motherboard chipset family AMD
Number of chassis fan connectors 6
Number of CPU fan connectors 2
Number of EPS power connectors (8-pin) 2
Number of HDDs supported 4
Number of M.2 (M) slots 4
Number of RGB LED pin headers 4
Number of SATA III connectors 4
Number of water pump connectors 3
On-board graphics card Yes
On-board graphics card model AMD Radeon Graphics
Parallel processing technology support Not supported
PC health monitoring Fan/Noise/Temperature/Voltage/Water cooling
PCI Express x16 (Gen 3.x) slots 1
PCI Express x16 (Gen 4.x) slots 1
PCI Express x16 (Gen 5.x) slots 1
Product colour White
Products per shipping (inner) case 1
RGB LED pin header Yes
S/PDIF out port Yes
Screws included Yes
Summary GIGABYTE X870 AORUS ELITE WIFI7 ICE Motherboard - Supports AMD Ryzen 9000 CPUs, 16+2+2 Phases Digital VRM, up to 8200MHz DDR5 (OC), 3xPCIe 5.0 + 1xPCIe 4.0, Wi-Fi 7, 2.5GbE LAN, USB 4. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series. Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 10. Maximum resolution: 4096 x 2160 pixels, On-board graphics card model: AMD Radeon Graphics. Ethernet interface type: 2.5 Gigabit Ethernet, LAN controller: Realtek RTL8125, Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Supported memory clock speed (max) 8200
System Management BIOS (SMBIOS) version 2.7
Top Wi-Fi standard Wi-Fi 7 (802.11be)
Total number of SATA connectors 4
TPM connector Yes
Unit Calculated Volume 0.01018
Unit Calculated Weight 2.59
Units per Shipping Box 5
USB 3.2 Gen 1 (3.1 Gen 1) connectors 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 2
USB 3.2 Gen 2x2 connectors 1
USB4 Gen 3x2 ports quantity 2
Warranty period 3
WiFi-AP antenna jack 2
WLAN controller model MediaTek MT7925
Процессор
Compatible processor series AMD Ryzen 7000 Series/AMD Ryzen 8000 Series/AMD Ryzen 9000 Series
Processor manufacturer AMD
Сокет процессора AM5
Память
Maximum internal memory 256
Maximum internal memory supported by processor 256
Memory channels Dual-channel
Memory slots type DIMM
Supported memory clock speeds 4400/4800/5200/5600/6000/6200/6400/6600/6666/6800/7000/7200/7600/7800/8000/8200
Supported memory types DDR5-SDRAM
Unbuffered memory Yes
Тип памяти DDR5
Запоминающее устройство
Number of storage drives supported 8
RAID levels 0/1/10
RAID support Yes
Supported storage drive interfaces M.2
Supported storage drive types HDD & SSD
Порты
DisplayPort version 1.4
HDMI version 2.1
Headphone outputs 1
Microphone in Yes
USB 2.0 connectors 2
USB 2.0 ports quantity 4
Количество портов HDMI 1
Подключения
Bluetooth Yes
Ethernet interface type 2.5 Gigabit Ethernet
Ethernet LAN Yes
LAN controller Realtek RTL8125
Wi-Fi Yes
Wi-Fi standards 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)/Wi-Fi 6E (802.11ax)/Wi-Fi 7 (802.11be)
Версия Bluetooth 5.4
Батарея
Batteries included Yes
Battery type CR2032
Battery weight 3
Количество ячеек батареи 1
Технология аккумуляторов Lithium-Manganese Dioxide (LiMnO2)
Спецификация
ATX Power connector (24-pin) Yes
Audio output channels 7.1
BIOS Type UEFI AMI
Bundled software Norton® Internet Security (OEM version)LAN bandwidth management software
Component for PC
Country of origin China
DirectX version 12.0
EPS power connector (8-pin) Yes
Form factor ATX
HDCP Yes
Maximum resolution 4096 x 2160
Model X870 AORUS ELITE WIFI7 ICE
Motherboard chipset AMD X870
Motherboard form factor ATX
Number of displays supported 4
Number of memory slots 4
Package depth 270
Package height 80
Package weight 2740
Package width 335
Supported processor sockets Socket AM5
Weight 2400
Windows operating systems supported Windows 11 x64
Высота 35
Глубина 244
Чипсет X870
Ширина 305
