Mainboard, GIGABYTE, Intel H610, LGA1700, Micro-ATX, Memory DDR4, Memory slots 2, 1xPCI-Express 3.0 1x, 1xPCI-Express 4.0 16x, 1xM.2, 1x15pin D-sub, 1xHDMI, 4xUSB 2.0, 2xUSB 3.2, 1xPS/2, 1xRJ45, 3xAudio port, H610MHV3DDR4
Популярный
Последнее
- Бренд: Gigabyte
- Модель: H610M H V3 DDR4
- EAN: 4719331859718
- Наличие: 1
Наименование:
Gigabyte H610M H V3 DDR4
63.30€
Без PVN: 52.31€
- Обзор товара
- Характеристики
- Отзывы (0)
Характеристики
Specifikācija
12V power connector
Yes
ACPI version
5.0
Audio chip
Realtek ALC897
BIOS memory size
128
Clear CMOS button
Yes
Clear CMOS jumper
Yes
CPU fan connector
Yes
Desktop Management Interface (DMI) version
2.7
ECC ?ompatibility
ECC & Non-ECC
Front panel audio connector
Yes
Front panel connector
Yes
Graphics card
HD Graphics
Graphics card family
Intel
Lithium weight per battery
0.07
Motherboard chipset family
Intel
Number of HDDs supported
1
Number of M.2 (M) slots
1
Number of SATA III connectors
4
Parallel processing technology support
Not supported
PC health monitoring
Fan/Temperature/Voltage/Water cooling
Product colour
Black
Product Net Weight
0.68
Products per shipping (inner) case
1
RGB LED pin header
Yes
Serial port headers
1
Summary
GIGABYTE H610M H V3 DDR4 Motherboard - Supports Intel Core 14th CPUs, 4+1+1 Hybrid Phases Digital VRM, up to 3200MHz DDR4, 1xPCIe 3.0 M.2, GbE LAN, USB 3.2 Gen 1. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processor series: Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9,.... Supported memory types: DDR4-SDRAM, Maximum internal memory: 64 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD. Graphics card family: Intel, Graphics card: HD Graphics, Maximum resolution: 4096 x 2304 pixels. USB connector type: USB Type-A
Supported memory clock speed (max)
3200
System Management BIOS (SMBIOS) version
2.7
TPM connector
Yes
Unit Calculated Volume
0.004113
Unit Calculated Weight
0.753
Units per Shipping Box
10
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
Warranty period
3
Процессор
Compatible processor series
Intel Celeron/Intel Core i3/Intel Core i5/Intel Core i7/Intel Core i9/Intel Pentium Gold
Processor manufacturer
Intel
Память
Maximum internal memory
64
Memory channels
Dual-channel
Memory slots type
DIMM
Supported memory clock speeds
2133/2400/2666/2933/3000/3200
Supported memory module capacities
12GB/16GB/1GB/2GB/32GB/4GB/8GB
Supported memory types
DDR4-SDRAM
Unbuffered memory
Yes
Тип памяти
DDR4
Запоминающее устройство
Number of storage drives supported
5
Supported storage drive interfaces
M.2,SATA III
Supported storage drive types
HDD & SSD
Порты
DisplayPorts quantity
2
DVI-D ports quantity
1
Headphone outputs
3
Microphone in
Yes
USB 2.0 connectors
2
USB 2.0 ports quantity
4
USB connector type
USB Type-A
Количество портов HDMI
1
Количество портов VGA (D-Sub)
1
Подключения
Ethernet interface type
Gigabit Ethernet
Ethernet LAN
Yes
Wi-Fi
No
Порты локальной сети Ethernet (RJ-45)
1
Батарея
Batteries included
Yes
Battery type
CR2032
Battery weight
3
Количество ячеек батареи
1
Технология аккумуляторов
Lithium-Manganese Dioxide (LiMnO2)
Спецификация
ATX Power connector (24-pin)
Yes
Audio output channels
7.1
BIOS Type
UEFI AMI
Bundled software
Norton Internet Security (OEM version)LAN bandwidth management software
Component for
PC
Cooling type
Active
Country of origin
China
EPS power connector (8-pin)
Yes
Form factor
mATX
HDCP
Yes
Maximum resolution
4096 x 2304
Model
H610M H V3 DDR4
Motherboard chipset
Intel H610 Express
Motherboard form factor
micro ATX
Number of memory slots
2
Package depth
235
Package height
52
Package weight
684
Package width
265
PCI Express x1 slots
1
PCI Express x16 slots
1
Power source type
ATX
PS/2 ports quantity
1
Supported processor sockets
LGA 1700
Windows operating systems supported
Windows 10 x64/Windows 11 x64
Высота
35
Глубина
215
Кабели в комплекте
SATA
Чипсет
H610
Ширина
230
