Mainboard, GIGABYTE, Intel Z790, LGA1700, ATX, Memory DDR5, Memory slots 4, Z790EAGLEAX1.1

Популярный

Отзывы:

(0)

Наименование:

Gigabyte Z790 EAGLE AX 1.1

Бренд: Gigabyte
Модель: Z790 EAGLE AX 1.1
EAN: 4719331860998
Наличие: 5

198.62€

Без PVN: 164.15€

Кол-во:

Обзор товара
Характеристики
Отзывы (0)

Manufacturer page

Характеристики

Specifikācija

12V power connector Yes

ACPI version 5.0

Antenna included Yes

Audio chip Realtek ALC897

BIOS memory size 256

Clear CMOS button Yes

Clear CMOS jumper Yes

CPU fan connector Yes

Desktop Management Interface (DMI) version 2.7

Discrete graphics support Yes

ECC ?ompatibility ECC & Non-ECC

Front panel audio connector Yes

Front panel connector Yes

Lithium weight per battery 0.07

Maximum number of SMP processors 1

Motherboard chipset family Intel

Number of EATX power connectors 2

Number of HDDs supported 4

Number of M.2 (M) slots 3

Number of SATA III connectors 4

On-board graphics card No

Parallel processing technology support Not supported

PC health monitoring Fan/Temperature/Voltage/Water cooling

PCI Express x1 (Gen 3.x) slots 2

PCI Express x16 (Gen 3.x) slots 1

PCI Express x16 (Gen 4.x) slots 1

PCI Express x16 (Gen 5.x) slots 1

Product colour Brown

Product Net Weight 0.7

Products per shipping (inner) case 1

RGB LED pin header Yes

S/PDIF out port Yes

Summary GIGABYTE Z790 EAGLE AX Motherboard - Supports Intel Core 14th Gen CPUs, 12+1+１Phases Digital VRM, up to 7600MHz DDR5 (OC), 3xPCIe 4.0 M.2, Wi-Fi 6E, 2.5GbE LAN, USB 3.2 Gen 2. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processor series: Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9,.... Supported memory types: DDR5-SDRAM, Maximum internal memory: 192 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 5, 10. Maximum resolution: 4096 x 2304 pixels. USB connector type: USB Type-A, USB Type-C

Supported memory clock speed (max) 7600

System Management BIOS (SMBIOS) version 2.7

Thunderbolt headers 2

Top Wi-Fi standard Wi-Fi 6E (802.11ax)

Total number of SATA connectors 4

TPM connector Yes

Unit Calculated Volume 0.009969

Unit Calculated Weight 1.88

Units per Shipping Box 8

USB 3.2 Gen 1 (3.1 Gen 1) connectors 1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4

USB 3.2 Gen 2 (3.1 Gen 2) connectors 1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 1

USB 3.2 Gen 2x2 Type-C ports quantity 1

Warranty period 3

WiFi-AP antenna jack 2

WLAN controller model Intel Wi-Fi 6E AX211

Процессор

Compatible processor series Intel Celeron/Intel Core i3/Intel Core i5/Intel Core i7/Intel Core i9/Intel Pentium Gold

Processor manufacturer Intel

Память

Maximum internal memory 192

Maximum internal memory supported by processor 192

Memory channels Dual-channel

Memory slots type DIMM

Supported memory clock speeds 4400/4800/5200/5400/5600/5800/6000/6200/6400/6600/6800/7000/7200/7400/7600

Supported memory module capacities 12GB/16GB/1GB/2GB/32GB/48GB/4GB/8GB

Supported memory types DDR5-SDRAM

Unbuffered memory Yes

Тип памяти DDR5

Запоминающее устройство

Number of storage drives supported 7

RAID levels 0/1/10/5

RAID support Yes

Supported storage drive interfaces M.2,SATA III

Supported storage drive types HDD & SSD

Порты

DisplayPort version 1.2

DisplayPorts quantity 1

HDMI version 2.1

Headphone outputs 1

Microphone in Yes

USB 2.0 connectors 2

USB 2.0 ports quantity 2

USB connector type USB Type-A/USB Type-C

Количество портов HDMI 1

Подключения

Bluetooth Yes

Ethernet interface type 2.5 Gigabit Ethernet

Ethernet LAN Yes

Wi-Fi Yes

Wi-Fi standards 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)/Wi-Fi 6E (802.11ax)

Версия Bluetooth 5.3

Порты локальной сети Ethernet (RJ-45) 1

Батарея

Batteries included Yes

Battery type CR2032

Battery weight 3

Количество ячеек батареи 1

Технология аккумуляторов Lithium-Manganese Dioxide (LiMnO2)

Спецификация

ATX Power connector (24-pin) Yes

Audio output channels 7.1

BIOS Type UEFI AMI

Bundled software Norton® Internet Security (OEM version)LAN bandwidth management software

Component for PC

Country of origin China

EPS power connector (8-pin) Yes

Form factor ATX

HDCP Yes

Maximum resolution 4096 x 2304

Model Z790 EAGLE AX 1.1

Motherboard chipset Intel Z790 Express

Motherboard form factor ATX

Number of memory slots 4

Package depth 270

Package height 80

Package weight 1807.5

Package width 335

Power source type ATX

PS/2 ports quantity 1

Supported processor sockets LGA 1700

Windows operating systems supported Windows 10 x64/Windows 11 x64

Высота 35

Глубина 244

Кабели в комплекте SATA

Чипсет Z790

Ширина 305
