Mainboard, MSI, AMD B850, SAM5, Memory DDR5, Memory slots 4, B850MGAMINGPLUSWIFI6E
Популярный
Mainboard, MSI, AMD B850, SAM5, Memory DDR5, Memory slots 4, B850MGAMINGPLUSWIFI6E
Mainboard, MSI, AMD B850, SAM5, Memory DDR5, Memory slots 4, B850MGAMINGPLUSWIFI6E
Mainboard, MSI, AMD B850, SAM5, Memory DDR5, Memory slots 4, B850MGAMINGPLUSWIFI6E
Mainboard, MSI, AMD B850, SAM5, Memory DDR5, Memory slots 4, B850MGAMINGPLUSWIFI6E
Mainboard, MSI, AMD B850, SAM5, Memory DDR5, Memory slots 4, B850MGAMINGPLUSWIFI6E
Отзывы:
(0)
    Наименование:

    MSI B850M GAMING PLUS WIFI6E

  • Бренд: MSI
  • Модель: B850M GAMING PLUS WIFI6E
  • EAN: 4711377365345
  • Наличие: 50
145.22€
Без PVN: 120.02€
  • Обзор товара
  • Характеристики
  • Отзывы (0)

Mainboards for AMD CPUs

Характеристики
Specifikācija
1st M.2 highest PCI Express generation 5.0
1st M.2 largest key size 2280
2nd M.2 highest PCI Express generation 5.0
2nd M.2 largest key size 2280
3rd M.2 highest PCI Express generation 4.0
3rd M.2 largest key size 2280
ACPI version 6.5
Audio chip Realtek ALC897
BIOS memory size 256
CPU fan connector Y
ECC ?ompatibility non-ECC
Front panel audio connector Y
Front panel connector Y
Motherboard chipset family AMD
Number of CPU fan connectors 2
Number of HDDs supported 4
Number of M.2 (M) slots 3
Number of RGB LED pin headers 3
Number of SATA III connectors 4
Number of water pump connectors 1
On-board graphics card N
PCI Express x16 (Gen 3.x) slots 1
PCI Express x16 (Gen 4.x) slots 1
PCI Express x16 (Gen 5.x) slots 1
PCI Express x4 slots 1
Product colour Black
RGB LED pin header Y
Summary MSI B850M GAMING PLUS WIFI6E. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series. Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 10. Ethernet interface type: 5 Gigabit Ethernet, LAN controller: Realtek RTL8126, Top Wi-Fi standard: Wi-Fi 7 (802.11be). Component for: PC, Motherboard form factor: micro ATX, Motherboard chipset family: AMD
Supported memory clock speed (max) 8200
System Management BIOS (SMBIOS) version 3.7
Top Wi-Fi standard Wi-Fi 7 (802.11be)
Total number of SATA connectors 4
Unit Calculated Volume 0.006568
Unit Calculated Weight 1.72
Units per Shipping Box 10
USB 3.2 Gen 1 (3.1 Gen 1) connectors 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity 2
Процессор
Compatible processor series AMD Ryzen 7000 Series/AMD Ryzen 8000 Series/AMD Ryzen 9000 Series
Processor manufacturer AMD
Сокет процессора AM5
Память
Maximum internal memory 256
Memory channels Dual-channel
Memory slots type DIMM
Supported memory clock speeds 4800/6000/6400/8200
Supported memory types DDR5-SDRAM
Тип памяти DDR5
Запоминающее устройство
Number of storage drives supported 7
RAID levels 0/1/10
RAID support Y
Supported storage drive interfaces M.2
Supported storage drive types HDD & SSD
Порты
HDMI version 2.1
USB 2.0 connectors 4
Количество портов HDMI 1
Подключения
Bluetooth Y
Ethernet interface type 5 Gigabit Ethernet
Ethernet LAN Y
LAN controller Realtek RTL8126
Wi-Fi Y
Wi-Fi standards 802.11a/802.11b/802.11g/Wi-Fi 4 (802.11n)/Wi-Fi 5 (802.11ac)/Wi-Fi 6 (802.11ax)/Wi-Fi 6E (802.11ax)/Wi-Fi 7 (802.11be)
Версия Bluetooth 5.4
Порты локальной сети Ethernet (RJ-45) 1
Спецификация
ATX Power connector (24-pin) Y
Audio output channels 7.1
BIOS Type UEFI AMI
Component for PC
Form factor mATX
Model B850M GAMING PLUS WIFI6E
Motherboard chipset AMD B850
Motherboard form factor Micro ATX
Number of memory slots 4
PCI Express x16 slots 1
Supported processor sockets Socket AM5
Windows operating systems supported Windows 11 x64
Глубина 243.84
Чипсет B850
Ширина 243.84
