Power Supply, CHIEFTEC, 700 Watts, Efficiency 80 PLUS BRONZE, PFC Active, TPS-700S
Популярный
Power Supply, CHIEFTEC, 700 Watts, Efficiency 80 PLUS BRONZE, PFC Active, TPS-700S
Power Supply, CHIEFTEC, 700 Watts, Efficiency 80 PLUS BRONZE, PFC Active, TPS-700S
Power Supply, CHIEFTEC, 700 Watts, Efficiency 80 PLUS BRONZE, PFC Active, TPS-700S
Power Supply, CHIEFTEC, 700 Watts, Efficiency 80 PLUS BRONZE, PFC Active, TPS-700S
Power Supply, CHIEFTEC, 700 Watts, Efficiency 80 PLUS BRONZE, PFC Active, TPS-700S
Power Supply, CHIEFTEC, 700 Watts, Efficiency 80 PLUS BRONZE, PFC Active, TPS-700S
Отзывы:
(0)
    Наименование:

    CHIEFTEC TPS-700S

  • Бренд: CHIEFTEC
  • Модель: TPS-700S
  • EAN: 753263076502
  • Наличие: 30
51.73€
Без PVN: 42.75€
  • Обзор товара
  • Характеристики
  • Отзывы (0)

Desktop Computer PSU

Характеристики
Specifikācija
Cabling type Non-Modular
Compliance certificates RoHS
EPS cable length 650
EPS power connector (4+4 pin) Yes
Harmonized System (HS) code 84733020
Motherboard power cable length 650
PCI Express power cable length 500
Peripheral (Molex) power cable length 150/500
Power supply unit (PSU) form factor ATX
Product colour Black
Purpose PC
SATA power cable length 150/500
Summary Chieftec Task TPS-700S. Total power: 700 W, AC input voltage: 100 - 240 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 65 cm, SATA power cable length: 150,500 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Fan diameter: 12 cm, Number of fans: 1 fan(s). Compliance certificates: RoHS, Certification: ErP, CE, CB, EAC, TUV
Unit Calculated Volume 0.0045649
Unit Calculated Weight 2.07
Units per Shipping Box 1
Запоминающее устройство
Number of SATA power connectors 6
Спецификация
80 PLUS certification 80 PLUS Bronze
AC input frequency 47 - 63
AC input voltage 100 - 240
ATX power connector (20+4 pin) Yes
Certification ErP, CE, CB, EAC, TUV
Combined power (+12V) 648
Combined power (+5Vsb) 12.5
Combined power (-12V) 3.6
Fan diameter 120
Input current 10
Max output current (+12V) 54
Max output current (+3.3V) 19
Max output current (+5V) 17
Max output current (+5Vsb) 2.5
Max output current (-12V) 0.3
Motherboard power connector 20+4 pin ATX
Number of fans 1
Package type Box
Package weight 2150
PCI Express power connectors (6+2 pin) 2
Peripheral (Molex) power connectors (4-pin) 3
Power factor 0.9
Power Factor Correction (PFC) type Active
Power protection features Over voltage/Overheating/Overload/Short circuit/Under voltage
Supported motherboard form factors ATX
Total power 700
Weight 1740
Высота 87
Глубина 140
Ширина 150
Отзывы (0)

Нет отзывов об этом товаре.
