Switch, DAHUA, DH-SG4010-2F, SG4010-2F

Популярный

Отзывы:

(0)

Наименование:

DAHUA SG4010-2F

Бренд: DAHUA
Модель: SG4010-2F
EAN: 6923172597670
Наличие: 10

76.93€

Без PVN: 63.58€

Кол-во:

Обзор товара
Характеристики
Отзывы (0)

Manufacturer page

Характеристики

Specifikācija

Cloud-managed No

Compliance certificates CE

DC input voltage 12

DHCP features DHCP client

Fanless Yes

Fiber ethernet cabling technology 1000BASE-X

Product colour Black

Summary Dahua Technology SG4010-2F. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8, Console port: RJ-45. Full duplex. MAC address table: 8000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE.... DC input voltage: 12 V. Wall mountable

Sustainability compliance Yes

Unit Calculated Volume 0.007659

Unit Calculated Weight 1.18

Units per Shipping Box 12

Uplink ports quantity 2

Virtual LAN features Port-based VLAN/Tagged VLAN

Подключения

10G support No

Basic switching RJ-45 Ethernet ports quantity 8

Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)

Ethernet LAN data rates 10,100,1000

SFP module slots quantity 2

Спецификация

Access Control List (ACL) Yes

Console port RJ-45

Copper ethernet cabling technology 1000BASE-T/100BASE-TX/10BASE-T

Flow control support Yes

Forwarding rate 14.88

Full duplex Yes

Gigabit Ethernet (copper) ports quantity 8

Housing material Steel

IGMP snooping Yes

Input current 1

Jumbo frames 9000

Jumbo frames support Yes

LED indicators Yes

Link aggregation Yes

MAC address table 8000

Management protocols SNMP V1/V2C/V3

Mean time between failures (MTBF) 2322286.99

Multicast support Yes

Networking standards IEEE 802.1p/IEEE 802.1Q/IEEE 802.1x/IEEE 802.3/IEEE 802.3ab/IEEE 802.3ad/IEEE 802.3u/IEEE 802.3x/IEEE 802.3z

Number of VLANs 4000

Operating relative humidity (H-H) 5 - 95

Operating temperature (T-T) -10 - 55

Package depth 316

Package height 82

Package weight 1040

Package width 240

Packet buffer memory 4.1

Power consumption (max) 12

Power over Ethernet (PoE) No

Power source DC

Quality of Service (QoS) support Yes

Rack mounting No

Reset button Yes

Spanning tree protocol Yes

Switch layer L2

Switch type Managed

Switching capacity 20

VLAN support Yes

Wall mountable Yes

Web-based management Yes

Weight 640

Высота 28

Глубина 240

Название модели DH-SG4010-2F

Ширина 104
