    TP-LINK TL-SG1016DE

  • Brand: TP-LINK
  • Product Code: TL-SG1016DE
  • EAN: 6935364021269
  • Availability: 1
71.29€
Ex Tax: 58.92€
  • Product overview
  • Specification
  • Reviews (0)
  • Related products

Tags: Switches

Specifications
Specifikācija
Cable types supported Cat3/Cat5/Cat6
Compliance certificates CE/Federal Communications Commission (FCC)/RoHS
Number of queues 4
Product colour Black
Rack mount kit Yes
Rate limiting Yes
Store-and-forward Yes
Summary TP-Link 16-Port Gigabit Easy Smart Network Switch. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 16. MAC address table: 8000 entries, Switching capacity: 32 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x. Power connector: AC-in jack. Rack mounting, Form factor: 1U
Sustainability compliance Yes
Unit Calculated Volume 0.007796
Units per Shipping Box 8
Virtual LAN features Port-based VLAN/Tagged VLAN
Connections types
10G support No
Basic switching RJ-45 Ethernet ports quantity 16
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Specifications
AC input frequency 50/60
AC input voltage 100 - 240
Auto MDI/MDI-X Yes
Auto-negotiation Yes
Broadcast storm control Yes
Cables included AC
Compatible operating systems Windows
Copper ethernet cabling technology 1000BASE-T/100BASE-T/100BASE-TX
Depth 180
Flow control support Yes
Form factor 1U
Forwarding rate 23.8
Gigabit Ethernet (copper) ports quantity 16
Heat dissipation 34.52
Height 44
Housing material Metal
IGMP snooping Yes
Jumbo frames 9000
Jumbo frames support Yes
LED indicators Yes
Link aggregation Yes
MAC address table 8000
Maximum cable length 100
Model name 16-Port Gigabit Easy Smart Network Switch
Networking standards IEEE 802.1p/IEEE 802.1Q/IEEE 802.3/IEEE 802.3ab/IEEE 802.3u/IEEE 802.3x
Number of VLANs 32
Operating relative humidity (H-H) 10 - 90
Operating temperature (T-T) 0 - 40
Package depth 400
Package height 80
Package type Box
Package weight 1980
Package width 250
Packet buffer memory 0.512
Port mirroring Yes
Power connector AC-in jack
Power consumption (max) 19.15
Power over Ethernet (PoE) No
Power source AC
Power supply included Yes
Quality of Service (QoS) support Yes
Rack mounting Yes
Resource CD Yes
Storage relative humidity (H-H) 5 - 90
Storage temperature (T-T) -40 - 70
Switch layer L2
Switch type Managed
Switching capacity 32
User guide Yes
VLAN support Yes
Width 284
