NET GATEWAY UNIFI EXPRESS 7/UX7 UBIQUITI

Popular

Reviews:

(0)

Name:

Ubiquiti UX7

Brand: Ubiquiti
Product Code: UX7
EAN: 810010074300
Availability: 30

197.92€

Ex Tax: 163.57€

Product overview
Specification
Reviews (0)

Manufacturer page

Tags: Gateways/Controllers

Specifications

Specifikācija

Compliance certificates CE/Federal Communications Commission (FCC)/Industry Canada (IC)

Control display unit Yes

Electromagnetic (EMP) protection Yes

Electromagnetic (EMP) protection (air) 8

Electromagnetic (EMP) protection (contact) 4

Enclosure material Polycarbonate (PC)

Load balancing Yes

Product colour White

Product Net Weight 0.5

Routing protocols OSPF

Summary Ubiquiti UniFi Express 7. Product colour: White, Enclosure material: Polycarbonate (PC), LED indicators: Status. Antenna type: Internal, Antenna gain level (max): 6 dBi. Display type: LCM, Processor manufacturer: ARM, Processor family: ARM Cortex. Routing protocols: OSPF. Ethernet LAN data rates: 10,100,1000,2500,10000 Mbit/s, Networking standards: IEEE 802.1Q, WLAN data transfer rates supported: 1,2,5.5,6,6.5,9,11,12,18,24,36,48,54,300 Mbit/s

Unit Calculated Volume 0.007265

Unit Calculated Weight 1.27

Units per Shipping Box 10

Display parameters

Display diagonal 0.96

Display type LCM

Processor parameters

Built-in processor Yes

Number of processors installed 1

Processor frequency 1500

Processor manufacturer ARM

Processor model Cortex-A53

Processor family ARM Cortex

Memory parameters

Internal memory 3000

Connections types

Bluetooth Yes

Ethernet LAN (RJ-45) ports 2

Ethernet LAN data rates 10/100/1000/10000/2500

WAN connection Ethernet (RJ-45)

Wi-Fi Yes

Wireless connection Yes

WLAN data transfer rates supported 1/11/12/18/2/24/300/36/48/5.5/54/6/6.5/9

Specifications

AC adapter included Yes

Antenna gain level (max) 6

Antenna type Internal

Antennas quantity 4

Cables included LAN (RJ-45)/Power

Data transfer rate 5.7

Depth 117

DHCP server Yes

Firewall security Yes

Frequency band 2.4, 5, 6

Height 42.5

Input current 5

Input voltage 100 - 240

LED indicators Status

Model UX7

Multicast support Yes

Networking standards IEEE 802.1Q

Operating relative humidity (H-H) 5 - 95

Operating temperature (T-T) -10 - 40

Power consumption (max) 22

Quality of Service (QoS) support Yes

Reset button Yes

Security algorithms 802.1x RADIUS/IPSec/PPSK/TLS/WPA/WPA2/WPA3/WPA-Enterprise/WPA-PSK

VLAN support Yes

Weight 422

Width 117
