Switch, TELTONIKA, TSW101000000, PoE ports 4, 60 Watts, TSW101

Popular

Reviews:

(0)

Name:

Teltonika TSW101

Brand: Teltonika
Product Code: TSW101
EAN: 4779051840113
Availability: 20

71.21€

Ex Tax: 58.85€

Product overview
Specification
Reviews (0)

Manufacturer page

Tags: Switches

Specifications

Specifikācija

Harmonized System (HS) code 851762

Power over Ethernet (PoE) type supported Passive PoE

Product colour Metallic

Summary Teltonika TSW101. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 2000 entries, Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3az, IEEE 802.3u. Power connector: Terminal block (2-pin). Power over Ethernet (PoE)

Unit Calculated Volume 0.0008925

Unit Calculated Weight 0.44

Units per Shipping Box 1

Connections types

10G support No

Basic switching RJ-45 Ethernet ports quantity 5

Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)

Ethernet LAN data rates 10,100,1000

Specifications

Auto MDI/MDI-X Yes

Certification CE, REACH, RoHS, WEEETSW101 CETSW101 UKCATSW101 FCCTSW101 ICTSW101 CBTSW101 RCME-Mark

Depth 32

Height 95

Housing material Aluminium

Input voltage 9 - 30

International Protection (IP) code IP30

Jumbo frames 9216

Jumbo frames support Yes

LED indicators Power/Status

MAC address table 2000

Model TSW101

Model name TSW101000000

Networking standards IEEE 802.3/IEEE 802.3az/IEEE 802.3u

Operating relative humidity (H-H) 10 - 90

Operating temperature (T-T) -40 - 75

Power connector Terminal block (2-pin)

Power consumption (max) 2.31

Power consumption (typical) 0.64

Power over Ethernet (PoE) Yes

Power over Ethernet (PoE) ports quantity 4

Power over Ethernet (PoE) power per port 30

Power source DC

Switching capacity 10

Total Power over Ethernet (PoE) budget 120

Weight 354

Width 115
