WRL BRIDGE 450MBPS/AIRMAX NBE-5AC-GEN2 UBIQUITI
Popular
WRL BRIDGE 450MBPS/AIRMAX NBE-5AC-GEN2 UBIQUITI
WRL BRIDGE 450MBPS/AIRMAX NBE-5AC-GEN2 UBIQUITI
WRL BRIDGE 450MBPS/AIRMAX NBE-5AC-GEN2 UBIQUITI
WRL BRIDGE 450MBPS/AIRMAX NBE-5AC-GEN2 UBIQUITI
WRL BRIDGE 450MBPS/AIRMAX NBE-5AC-GEN2 UBIQUITI
WRL BRIDGE 450MBPS/AIRMAX NBE-5AC-GEN2 UBIQUITI
Reviews:
(0)
    Name:

    Ubiquiti NBE-5AC-GEN2

  • Brand: Ubiquiti
  • Product Code: NBE-5AC-GEN2
  • EAN: 810354026348
  • Availability: 5
89.73€
Ex Tax: 74.16€
  • Product overview
  • Specification
  • Reviews (0)

Tags: Bridges & Repeaters

Specifications
Specifikācija
Compliance certificates CE/RoHS
DC output current 0.5
Harmonized System (HS) code 85176990
Mounting bracket(s) included Yes
PoE+ Injector(s) Yes
Product colour White
RAM type DDR2
Summary Ubiquiti NanoBeam 5AC Gen 2. Maximum data transfer rate: 450 Mbit/s, Maximum transfer distance: 15000 m. Antenna gain level (max): 19 dBi. Frequency band: 5.15 - 5.875; 5.15 - 5.25; 5.25 - 5.35; 5.47 - 5.725; 5.725 - 5.85 GHz, Modulation: 16-QAM, 64-QAM, 256-QAM, BPSK, QPSK. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s. Security algorithms: WPA2
Unit Calculated Volume 0.006306
Unit Calculated Weight 1.26
Units per Shipping Box 10
Processor parameters
Processor frequency 720
Processor model MIPS 74Kc
Processor family Atheros
Memory parameters
Internal memory 128
Storage parameters
Flash memory 8
Connections types
Ethernet LAN Yes
Ethernet LAN (RJ-45) ports 2
Ethernet LAN data rates 10/100/1000
Ethernet LAN interface type Gigabit Ethernet
Wi-Fi Yes
Specifications
Antenna gain level (max) 19
Cables included AC
Certification CE, FCC, IC, RoHS
DC output voltage 24
Depth 189
Frequency band 5.15 - 5.875; 5.15 - 5.25; 5.25 - 5.35; 5.47 - 5.725; 5.725 - 5.85
Height 125
LED indicators LAN/Power/Signal strength
Material Plastic
Maximum data transfer rate 450
Maximum transfer distance 15000
Modulation 16-QAM/256-QAM/64-QAM/BPSK/QPSK
Mounting type Wall/Pole
Operating relative humidity (H-H) 5 - 95
Operating temperature (T-T) -40 - 80, -40 - 176
Power consumption (max) 8.5
Power over Ethernet (PoE) Yes
Power source type PoE
Product type Network bridge
Quantity per pack 1
Reset button Yes
Security algorithms WPA2
Surge protection Yes
Web-based management Yes
Weight 530
Width 189
Reviews (0)

There are no reviews for this product.
